Motorola ASTRO SPECTRA User Manual

6881086C22-B 71
TRN7391C Audio Interface Board Parts List
Ref. Des. Part Number Description
0984728L01 Socket, Yellow Conn.
0984728L01 Socket, Yellow Conn.
C100 2380090M15 CAP,0.33uF
C101 2311049A15 CAP,4.7uF
C102 2311049A14 CAP,4.7uF
C103 2113740B39 CAP,39pF
C104 2113740B57 CAP,220pF
C105 2113741B45 CAP,.01uF
C106 2113741B45 CAP,.01uF
C107 2113741B49 CAP,.015uF
C108 2113741B49 CAP,.015uF
C109 2113741B45 CAP,.01uF
C110 2113740B73 CAP,1000pF
C111 2113740B61 CAP,330pF
C112 2311049A08 CAP,1uF
C113 2113740B33 CAP,22pF
C114 2311049A45 CAP,10uF
C115 2113740B57 CAP,220pF
C116 2113741B49 CAP,.015uF
C117 2113741B49 CAP,.015uF
C118 2113741B49 CAP,.015uF
C119 2311049A15 CAP,4.7uF
C120 2113740B39 CAP,39pF
C121 2113740B39 CAP,39pF
C122 2113741B69 CAP,0.1uF
C123 2113741B69 CAP,0.1uF
C124 2311049A08 CAP,1uF
C125 2380090M25 CAP,100uF
C126 2311049A45 CAP,10uF
C127 2113741B69 CAP,0.1uF
C128 2113741B69 CAP,0.1uF
C135 2311049A08 CAP,1uF
C136 2311049A08 CAP,1uF
C137 2113741B69 CAP,0.1uF
C138 2113740B65 CAP,470pF
C139 2113741B69 CAP,0.1uF
C140 2113740B65 CAP,470pF
C141 2380090M25 CAP,100uF
C142 2380090M25 CAP,100uF
C143 2113740B65 CAP,470pF
C144 2113740B65 CAP,470pF
C145 2113740B65 CAP,470pF
C146 2113740B65 CAP,470pF
C147 2113741B69 CAP,0.1uF
C148 2113740B65 CAP,470pF
C149 2113740B65 CAP,470pF
C150 2113740B65 CAP,470pF
C151 2113740B65 CAP,470pF
C152 2113740B65 CAP,470pF
C153 2113740B65 CAP,470pF
C154 2113740B65 CAP,470pF
C155 2113740B65 CAP,470pF
C156 2113740B65 CAP,470pF
C157 2311049A08 CAP,1uF
C158 2113741B69 CAP,0.1uF
C159 2113741B69 CAP,0.1uF
C160 2113741B69 CAP,0.1uF
CR102 4813833C04 BAV70
CR103 4813833C03 BAW56
CR104 4813833C10 MMBD6050
CR105 4813833C10 MMBD6050
J1 2882505T15 CONN_P
J2 2882505T04 CONN_P
J3 2882505T15 CONN_P
Ref. Des. Part Number Description
J4 2884324M07 CONN_P
J5 2884324M08 CONN_P
J6 2884324M09 CONN_P
J11 2880004T02 CONN_P
J13 2884324M08 CONN_P
J14 2880001R03 CONN_P
J15 2880001R03 CONN_P
JU101 0611077A01 RES, 0
Q101 4813824A10 MMBT3904
Q102 4813824A10 MMBT3904
Q103 4813822A07 MJD340
Q104 4813822A07 MJD340
Q106 4813824A18 MMBT4403
Q107 4813824A11 MMBT2222A
Q108 4813824A18 MMBT4403
R100 0611077B19 RES,68K
R101 0611077A98 RES,10K
R102 0611077B05 RES,18K
R103 0611077B14 RES,43K
R104 0611077B11 RES,33K
R105 0611077B05 RES,18K
R106 0611077B23 RES,100K
R107 0611077B03 RES,15K
R108 0611077B23 RES,100K
R109 0611077B23 RES,100K
R110 0611077B15 RES,47K
R111 1813905A14 RES,200K
R112 0611077B23 RES,100K
R113 0611077G81 RES,84.5K
R114 0611077A98 RES,10K
R115 0611077B28 RES,160K
R116 0611077A98 RES,10K
Ref. Des. Part Number Description
R117 0611077B30 RES,200K
R118 0611077G81 RES,84.5K
R119 0611079B23 RES,100K
R120 0611077B30 RES,200K
R121 0611077A90 RES,4.7K
R122 0611077B30 RES,200K
R123 0611077A68 RES,560
R124 0611077B30 RES,200K
R125 0611077B30 RES,200K
R126 0611077B15 RES,47K
R127 0611077A74 RES,1K
R128 0611077B15 RES,47K
R129 0611077B15 RES,47K
R130 0611077A74 RES,1K
R131 0611077A98 RES,10K
R132 0611077B15 RES,47K
R133 0611077A98 RES,10K
R134 0611077A90 RES,4.7K
R135 0611077A90 RES,4.7K
R136 0611077A74 RES,1K
R137 0611072A22 RES,75
R138 0611072A22 RES,75
R139 0611077A76 RES,1.2K
R140 0611077A98 RES,10K
R141 0611077A80 RES,1.8K
R142 0611077A98 RES,10K
R143 0611077B14 RES,43K
R144 0611077A98 RES,10K
R145 0611077B15 RES,47K
R146 0611077A26 RES,10
R147 0611072A47 RES,820
R148 0611077A26 RES,10
Ref. Des. Part Number Description
