Installation: Clock/VU Meter Setup (Optional)
12 6881086C22-B
Clock/VU Meter
Setup (Optional)
General The clock shows the time, day, month, and year.
Operation Press the mode button to change the display cyclically between the time,
month.day, and year.
Time Setting After power up, the display flashes and the clock starts from the default time
of: 00:00:00, month.day: 1.1, year: 1990.
1. Press the mode button until the time is displayed (HH:MM).
2. Press the set button for 5 seconds.
3. Press the mode button to reset the seconds. The display shows the
seconds.
4. Press the set button. The display shows the hours and minutes (flashing).
5. Press the mode button until the correct minutes are displayed.
6. Press the set button. The display shows the hours (flashing) and minutes.
7. Press the mode button until the desired hour is displayed.
Table 7. Tone Table Selection
SEL #4 SEL #3 SEL #2 SEL #1
Selected Tone
Table
OFF OFF OFF OFF Standard
OFF OFF OFF ON CentraCom II
OFF OFF ON OFF No Mode Sel
OFF OFF ON ON Mode 1 only
OFF ON OFF OFF No Mode 1
OFF ON OFF ON Not supported
OFF ON ON OFF Not supported
OFF ON ON ON Not supported
ON OFF OFF OFF Not supported
ON OFF OFF ON Not supported
ON OFF ON OFF Not supported
ON OFF ON ON Not supported
ON ON OFF OFF Not supported
ON ON OFF ON Not supported
ON ON ON OFF Not supported
ON ON ON ON Not supported
