Motorola ASTRO SPECTRA User Manual

Theory of Operation: Power-Up Self-Check Errors
6881086C22-B 33
Table 15. ASTRO Spectra Consolette Power-Up Self-Check Error Codes
Error
Code
Description
Troubleshooting
Chart
01/02 External EEPROM checksum non-fatal error See Note 1
01/81 ROM checksum failure See Note 1
01/82 External EEPROM checksum failure See Note 1
01/84 EEPROM is blank See Note 1
01/88 RAM failure —Note: Not a checksum failure See Note 1
01/90 General hardware failure See Note 1
01/92 Internal EEPROM checksum failure See Note 1
02/81 DSP ROM checksum failure See Note 1
02/82 DSP RAM 1 failure See Note 1
02/84 DSP RAM 2 failure See Note 1
02/88 DSP RAM failure —Note: Not a checksum failure See Note 1
02/90 General DSP hardware failure (DSP start-up
message not received correctly)
See Note 1
02/A0 ADSIC checksum failure See Note 1
09/10 Secure option not communicating with radio See Note 1
09/90 Secure hardware failure See Note 1
1C/10 TRC option not communicating with radio See Note 2
1C/81 TRC ROM checksum failure See Note 3
1C/82 TRC configuration register corrupted See Note 3
1C/88 TRC RAM failure —Note: Not a checksum failure See Note 3
