Motorola ASTRO SPECTRA User Manual

6881086C22-B xiii
ASTRO Spectra Consolette Model Chart
ASTRO Spectra Consolette Model Chart
Key: X = Item Included, D = Item Deleted, A = Item Added
(Model Chart continued on next page)
MODEL OR OPTION NUMBER DESCRIPTION
L04JKH9PW9_ 20-25W 136-162MHZ W/Digital Rem Controller
L04KKH9PW9_ 20-25W 146-174MHZ W/Digital Rem Controller
L04QKH9PW9_ 20-40W 403-433MHZ W/Digital Rem Controller
L04RHH9PW9_ 10-25W 438-470MHZ W/Digital Rem Controller
L04RKH9PW9_ 20-40W 450-482MHZ W/Digital Rem Controller
L04RKH9PW9_SP01 10-25W 453-488MHZ W/Digital Rem Controller
L04SKH9PW9_ 20-40W 482-512MHZ W/Digital Rem Controller
L04UJH9PW9_ 35W 806-870MHZ W/Digital Rem Controller
L04JKH9PW7_ 20-25W 136-162MHZ W/Local Control
L04KKH9PW7_ 20-25W 146-174MHZ W/Local Control
L04QKH9PW7_ 20-40W 403-433MHZ W/Local Control
L04RHH9PW7_ 10-25W 438-470MHZ W/Local Control
L04RKH9PW7_ 20-40W 450-482MHZ W/Local Control
L04RKH9PW7_SP01 10-25W 453-488MHZ W/Local Control
L04SKH9PW7_ 20-40W 482-512MHZ W/Local Control
L04UJH9PW7_ 35W 806-870MHZ W/Local Control
L146 Tone Rem Control Option (All Local Control Models)
ITEM NUMBER DESCRIPTION
XXXXXXXXXXXXXXXX HPN4005_ Power Supply, 13.8V, 10-Amp
XXXXXXXXXXXXXXXX FRN5358_ Fan
XXXXXXXXXXXXXXXX HLN5558_ Command Board
XXXXXXXXXXXXXXXX HLN6282_ Power Cord, 100V
XXXXXXXXXXXXXXXX HLN6344_ Interface Board
XXXXXXXXXXXXXXXX HLN6458_ Vocoder Controller (VOCON) Board
XXXXXXXXXXXXXXXX THN6676_ Housing Assembly
XXXXXXXXXXXXXXXX TKN8676_ Cable Kit
XXXXXXXXXXXXXXXX HLN6607_ Front Panel Assembly
XXXXXXXXXXXXXXXXDTRN7391_ Audio Interface Board
X XXXXXXXAPLN1360_ Tone Remote Control Board
X XXXXXXX HLN6396_ Control Head Board
X XXXXXXX HLN6441_ Control Head Display
X XXXXXXX HMN1050_ Desk Microphone
X XXXXXXX TRN7392_ Control Head Bracket Hardware
X XXXXXXX TRN7393_ Control Head Interface Board
X XXXXXXX TRN7394_ Speaker Hardware
X XXXXXXX HLN6523_ Control Head Button (Trunking Only)
X XXXXXXX HLN6105_ Spare Button Kit
X XXXXXXX HLN6688_ Spare Button Kit
XXXXXXXXXXXXXX HLN6418_ Transceiver Hardware
XXXXXXXX TGN6150_ Blank Control Head Panel
XXXXXXXX HLN6185_ Remote Control Head Hardware
XX X X HLN6060_ Radio Dash Hardware, Mid-Power
X XXX X XXX HLN6073_ Radio Dash Hardware, Mid-Power, UHF
X X HLN6126_ Radio Dash Hardware, Mid-Power TD
X X HLN6127_ Radio Dash Hardware, Low-Power TD
XX X X HLD6022_ PA Board, 50W, VHF
X X HLE6049_ PA Board, 40W, Range 1, UHF
X X HLE6062_ PA Board, 25W, Range 2, UHF
XX XX HLE6043_ PA Board, 40W, Range 3, UHF
X X HLE6044_ PA Board, 40W, Range 4, UHF
X X HLF6077_ PA Board, 35W, 800MHz
XX X X HRN6014_ ASTRO RF Board, VHF
X XXX X XXX HRN6020_ ASTRO RF Board, UHF
X X HRN4010_ RF Board, Low-Pass, UHF
