Motorola GP series Detailed Service Manual

Chapter 3
SERVICE AIDS
1.0 Recommended Test Tools
Table 3-1 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Table 3-1 Service Aids
Motorola Part
Number
Description Application
6680387A59
6680387A64
6680387A65
0180382A31
Extractor, 2-contact
Heat controller with safety stand or
Safety stand only
Safety stand only
Portable desoldering unit
Removal of discrete surface-mounted
devices
RLN4460_ Portable & Mobile Test Set Enables connection to the audio/
accessory jack.
Allows switching for radio testing.
RKN4074_ RIB/Radio/Test Set Interconnect Cable
(for all Models except GP1280).
Connects radio to Computer.
RKN4075_ Programming Cable with internal RIB
(for all Models except GP1280).
Connects radio to Computer.
RLN4008_ Radio Interface Box (RIB). Enables communications between the
radio and the computer’s serial
communications adapter.
5885705M01 BNC Adaptor Adapts radio’s antenna port to BNC
cabling of test equipment.
5880384G68 SMA to BNC Adaptor Adapts radio’s antenna port to BNC
cabling of test equipment, 800MHz only.
HKN9743_ MAP27 Cable (for GP1280 only). Connects radio to computer for MAP27
applications in MPT requirements.
HLN9742_ Flash Upgrade Adapter Provides connections to the computer or
RIB programming /test cable.
RLN4510_ Battery Elliminator 7.5 VDC Includes protection circuit.
0180305G54 Battery Adapter to RLN4510 Connects radio to Battery Elliminator.
8180384F68 Bench Test Housing Eliminator
(for all Models except GP1280).
Provides for troubleshooting of the radio
when the housing is removed.
8180384F66 Bench Test Housing Eliminator
(long housing, GP1280 only).
Provides for troubleshooting of the radio
when the housing is removed.
EPN4040_ Wall-Mounted Power Supply (UK). for RLN4008
EPN4041_ Wall-Mounted Power Supply (220VAC). for RLN4008
3080369B71 Computer Interface Cable 25 to 9 pin (RLN4008_ to IBM PC).
3080369B72 Computer Interface Cable 9 to 9 pin (RLN4008_ to IBM PC).
