Motorola GP series Detailed Service Manual

800MHz PCB Parts List (Rev A/B) 3-21
3.0 800MHz PCB Parts List (Rev A/B)
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A01 Connector Multi_Pin 37A01
B503 3980502Z01 Mechanical
B504 3980501Z01 Mechanical
C101 2113740F45 Capacitor Chip 56pF
C104 2113740F15 Capacitor Chip 3.3pF
C105 2113740F06 Capacitor Chip 1.3pF
C106 2113740F23 Capacitor Chip 6.8pF
C107 2113740F03 Capacitor Chip 1pF
C108 2113743N46 Capacitor Chip 68pF
C109 2113740F20 Capacitor Chip 5.1pF
C110 2113740F12 Capacitor Chip 2.4pF
C111 2113743N32 Capacitor Chip 18pF
C112 2113743N46 Capacitor Chip 68pF
C113 2113740F45 Capacitor Chip 56pF
C114 2103689A19 Capacitor Chip 6.0pF
C115 2103689A05 Capacitor Chip 12.0pF
C116 to
C117
2113743N46 Capacitor Chip 68pF
C118 2103689A08 Capacitor Chip 18.0pF
C119 2113743N46 Capacitor Chip 68pF
C121 2113743N60 Capacitor Chip 5pF
C124 to
C125
2113743N46 Capacitor Chip 68pF
C126 2113743L13 Capacitor Chip 680pF
C127 2113743N12 Capacitor Chip 2.7pF
C128 2113743N44 Capacitor Chip 56pF
C129 2113743M08 Capacitor Chip .022µF
C130 2113743L13 Capacitor Chip 680pF
C131 2113743N46 Capacitor Chip 68pF
C132 2113743L41 Capacitor Chip .01µF
C133 to
C135
2113743N44 Capacitor Chip 56pF
C136 2113743M24 Capacitor Chip 0.1µF
C138 2113743N44 Capacitor Chip 56pF
C139 2113743M08 Capacitor Chip .022µF
C140 2113743N32 Capacitor Chip 18pF
C141 2113743N18 Capacitor Chip 4.7pF
C142 2113743M08 Capacitor Chip .022µF
C143 2113743L29 Capacitor Chip 3300pF
C144 2311049A08 Capacitor Tantalum 1µF
C146 2113743N46 Capacitor Chip 68pF
C147 to
C148
2113743N32 Capacitor Chip 18pF
C149 2113743N44 Capacitor Chip 56pF
C150 2113743N32 Capacitor Chip 18pF
C151 2113743N46 Capacitor Chip 68pF
C152 2113743N32 Capacitor Chip 18pF
C153 2113743N46 Capacitor Chip 68pF
C154 to
C155
2113743N44 Capacitor Chip 56pF
C157 2113743N46 Capacitor Chip 68pF
C158 to
C159
2113743N44 Capacitor Chip 56pF
C160 2113743N46 Capacitor Chip 68pF
C161 2113743N32 Capacitor Chip 18pF
C162 2113743N48 Capacitor Chip 82pF
C163 2113743N46 Capacitor Chip 68pF
C164 2113743N32 Capacitor Chip 18pF
C200 2113743F18 Capacitor Chip 2.2µF
C201 2113743N46 Capacitor Chip 68pF
C202 2113743F18 Capacitor Chip 2.2µF
C203 2311049A57 Capacitor Tantalum 10µF
C204 2113743M24 Capacitor Chip 0.1µF
C205 2113743L41 Capacitor Chip .01µF
C206 2113743M24 Capacitor Chip 0.1µF
C207 2113743F18 Capacitor Chip 2.2µF
C208 2113743M24 Capacitor Chip 0.1µF
C209 2311049A57 Capacitor Tantalum 10µF
C210 2113743N46 Capacitor Chip 68pF
C211 2311049A09 Capacitor Tantalum 2.2µF
C212 to
C213
2113743M24 Capacitor Chip 0.1µF
C214 2113743F18 Capacitor Chip 2.2µF
C215 2113743M24 Capacitor Chip 0.1µF
C216 2113743N46 Capacitor Chip 68pF
C217 2113743F18 Capacitor Chip 2.2µF
C218 2311049A01 Capacitor Tantalum 0.1µF
C219 2113743N46 Capacitor Chip 68pF
C220 2311049A05 Capacitor Tantalum 0.47µF
C221 to
C224
2113743N46 Capacitor Chip 68pF
C225 to
C226
2113743E12 Capacitor Chip .047µF
C227 2113743N46 Capacitor Chip 68pF
C228 2113743N02 Capacitor Chip 0.75pF
C229 2113743F18 Capacitor Chip 2.2µF
C230 2113743N46 Capacitor Chip 68pF
C231 2113741F17 Capacitor Chip 470pF
C232 2113743N46 Capacitor Chip 68pF
C233 2113743L17 Capacitor Chip 1000pF
C234 2311049A59 Capacitor Tantalum 10µF
C235 2113743N44 Capacitor Chip 56pF
(PMUF1046 & PMUF1047
only)
C236 2113743N08 Capacitor Chip 1.6pF
(PMUF1046 & PMUF1047
only)
C237 2113740F63 Capacitor Chip 330pF
(PMUF1046 & PMUF1047
only)
Circuit
Ref
Motorola
Part No.
Description
C238 2113743M24 Capacitor Chip 0.1µF
(PMUF1063 & PMUF1064
only)
2113743L41 Capacitor Chip .01µF C239
(PMUF1063 & PMUF1064
only)
C240 2113743L41 Capacitor Chip .01µF
C241 2113743N46 Capacitor Chip 68pF
(PMUF1063 & PMUF1064
only)
C243 2113743N34 Capacitor Chip 22pF
C244 to
C247
2113743L41 Capacitor Chip .01µF
C253 2113743N48 Capacitor Chip 82pF
C254 2113743N46 Capacitor Chip 68pF
C256 2113743N03 Capacitor Chip 1pF
C257 2113743N46 Capacitor Chip 68pF
C258 2113743M24 Capacitor Chip 0.1µF
C259 2113743F18 Capacitor Chip 2.2µF
C260 2113743N46 Capacitor Chip 68pF
C262 2113743M24 Capacitor Chip 0.1µF
C263 2113743N46 Capacitor Chip 68pF
C264 2113743M24 Capacitor Chip 0.1µF
C265 2113743N69 Capacitor Chip 1.8pF
C266 to
C267
2113743N09 Capacitor Chip 2pF
C268 2113743N03 Capacitor Chip 1pF
C269 2113743M12 Capacitor Chip .033µF
C270 2113743M24 Capacitor Chip 0.1µF
C271 2113743N20 Capacitor Chip 5.6pF
C273 2113743N14 Capacitor Chip 3.3pF
C274 2113743N46 Capacitor Chip 68pF
C275 2113743N05 Capacitor Chip 1.2pF
C276 2113743N13 Capacitor Chip 3pF
C277 2113743N20 Capacitor Chip 5.6pF
C278 2113743N16 Capacitor Chip 3.9pF
C280 2113743M24 Capacitor Chip 0.1µF
C281 to
C282
2113743N46 Capacitor Chip 68pF
C284 2113743N44 Capacitor Chip 56pF
C285 2113743M24 Capacitor Chip 0.1µF
C286 2113743N46 Capacitor Chip 68pF
C287 2113743N50 Capacitor Chip 100pF
C289 2113743M12 Capacitor Chip .033µF
C290 2113743N44 Capacitor Chip 56pF
C300 2113743N65 Capacitor Chip 8pF
C301 2113743N46 Capacitor Chip 68pF
C303 2113743N26 Capacitor Chip 10pF
C304 2113743M24 Capacitor Chip 0.1µF
C305 2113743N44 Capacitor Chip 56pF
Circuit
Ref
Motorola
Part No.
Description
C306 to
C307
2113743N46 Capacitor Chip 68pF
C308 2113743N05 Capacitor Chip 1.2pF
C310 2113743N30 Capacitor Chip 15pF
C311 2113743N48 Capacitor Chip 82pF
C312 2113743N37 Capacitor Chip 30pF
C313
C314
2113743N48 Capacitor Chip 82pF
C315 2113743N65 Capacitor Chip 8pF
C316 to
C317
2113743N44 Capacitor Chip 56pF
C350 2311049A59 Capacitor Tantalum 10µF
C352 2113743M08 Capacitor Chip .022µF
C353 2113743A23 Capacitor Chip 0.22µF
C354 2113743M08 Capacitor Chip .022µF
C355 2113743E20 Capacitor Chip 0.1µF
C356 2113743N50 Capacitor Chip 100pF
C357 2113743F16 Capacitor Chip 1µF
C358 2113743M24 Capacitor Chip 0.1µF
C359 to
C360
2113743A23 Capacitor Chip 0.22µF
C361 to
C362
2113743R33 Capacitor Chip 4700pF
C363 to
C364
2113743F16 Capacitor Chip 1µF
C365 2113743N65 Capacitor Chip 8pF
C366 2113743F16 Capacitor Chip 1µF
C367 2113743M08 Capacitor Chip .022µF
C369 2113743R33 Capacitor Chip 4700pF
C370 2113743M24 Capacitor Chip 0.1µF
C371 2113743R33 Capacitor Chip 4700pF
C372 2113743A23 Capacitor Chip 0.22µF
C373 2311049A59 Capacitor Tantalum 10µF
C374 2113743E07 Capacitor Chip .022µF
C376 2113743N09 Capacitor Chip 2pF
C377 2113743N34 Capacitor Chip 22pF
C378 2113743N11 Capacitor Chip 2.4pF
C379 2113740A82 Capacitor Chip 1500pF
C380 2109720D14 Capacitor Chip 0.1µF
C381 2113743E20 Capacitor Chip 0.1µF
C382 2311049A59 Capacitor Tantalum 10µF
C383 2113743M08 Capacitor Chip .022µF
C385 2113743N25 Capacitor Chip 9.1pF
C386 2113743N29 Capacitor Chip 13pF
C387 2113743N30 Capacitor Chip 15pF
C388 to
C390
2113743N29 Capacitor Chip 13pF
C391 2113741F49 Capacitor Chip .01µF
C392 2113743F16 Capacitor Chip 1µF
C393 2113743E20 Capacitor Chip 0.1µF
C400 2113743L41 Capacitor Chip .01µF
