Motorola GP series Detailed Service Manual

1-3 Parts List (Keypad Basic)
3.0 Parts List (Keypad Basic)
Circuit Ref
Motorola
Part No.
Description
C601 2113743N50 100 pF
C602 2311049A86 1 uF
C603 2113743N50 100 pF
C604 2113743N50 100 pF
C605 2113743N50 100 pF
C606 2113743N50 100 pF
C607 2113743L17 1000 pF
C608 2113743N50 100 pF
C609 2113743N50 100 pF
C610 2113743N50 100 pF
C611 2113743N50 100 pF
C612 2113743N50 100 pF
C613 2113743N50 100 pF
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
D607 4880479U01 LED
D608 4880479U01 LED
E609 2480640Z01 IND BEAD
E613 2480640Z01 IND BEAD
E614 2480640Z01 IND BEAD
E615 2480640Z01 IND BEAD
E616 2480640Z01 IND BEAD
E617 2480640Z01 IND BEAD
E618 2480640Z01 IND BEAD
E619 2480640Z01 IND BEAD
E620 2480640Z01 IND BEAD
E621 2480640Z01 IND BEAD
J601 0980521Z01 44 pin connector
J602 0905505Y03 18 pin connector
Q601 4813824A10 40V.2A NPN
TRANSISTOR
Q602 4813824A10 40V.2A NPN
TRANSISTOR
Q603 4813824A17 40V.2A PNP
TRANSISTOR
Q604 4813824A10 40V.2A NPN
TRANSISTOR
Q605 4813824A10 40V.2A NPN
TRANSISTOR
Q606 4813824A10 40V.2A NPN
TRANSISTOR
Q607 4813824A10 40V.2A NPN
TRANSISTOR
Q608 4813824A10 40V.2A NPN
TRANSISTOR
R601 0662057M98 10K
R602 0662057A66 51K
R603 0662057M82 2.2K
R605 0662057M01 0 ohm
R610 0662057M01 0 ohm
R622 0662057V20 51K
R623 0662057N16 51K
R624 0662057V20 51K
R625 0662057N41 560K
R626 0662057V05 13K
R627 0662057V05 13K
R628 0662057N47 1.0MEG
R629 0662057V11 22K
R630 0662057V11 22K
R631 0662057V18 43K
R632 0662057V18 43K
R633 0662057V30 130K
R634 0662057V30 130K
R641 0662057M42 47K
R643 0662057M42 47K
R644 0662057M42 47K
R647 0662057M42 47K
U602 5102463J49 LMC7211
comparator
8480574Z05 PC Board, Keypad
Circuit Ref
Motorola
Part No.
Description
