Motorola GP series Detailed Service Manual

Test Equipment 3-3
2.0 Test Equipment
Table 3-3 lists test equipment required to service the radio and other two-way radios.
Table 3-3 Recommended Test Equipment
Motorola Part
Number
Description Characteristics
Application
R2600_
RLN5069_
RLN4361_
RLN4423_
RLN4485_
1580357B77
Comms System Analyzer
(non MPT).
Tracking Generator Option.
CCITT Filter.
Spectrum Analyzer and
Oscilloscope with Markers.
Test Set Ups Memory.
Canvas Case
This monitor will
substitute for items
with an asterisk*
with 600 Ohm Meter
Load.
High Performance
option.
Programmable
Protects Units
Frequency/deviation meter and
signal generator for widerange
troubleshooting and alignment.
Option for R2600_
Option for R2600_
Option for R2600_
Allows storage of complete
screen values.
When used in the Field.
or
R2680_HS
RLN1022_
RLN1023_
RLN4361_
RLN4423_
1580357B77
Comms System Analyzer
( MPT1327)
MPT1327 Hardware
MPT1327 Software
CCITT Filter
Spectrum Analyzer and
Oscilloscope with Markers
Canvas Case
This monitor will
substitute for items
with an asterisk*.
with 600 ohm Meter
Load
High Performance
option.
Protects Units
Frequency/deviation meter and
signal generator for widerange
troubleshooting and alignment.
Option for R2680_HS
Option for R2680_HS
Option for R2680_HS
Option for R2680_HS
When used in the Field.
or
R2670_
RLN4498_
1580357B77
Comms System Analyzer
with FDMA.
Analog Trunking
Smartnet/Zone.
Canvas Case
This monitor will
substitute for items
with an asterisk*.
Protects Units
Frequency/deviation meter and
signal generator for widerange
troubleshooting and alignment.
Option for R2670_
When used in the Field.
* WADN4133_ Oscilloscope Analog 2 Channel
40MHz bandwidth,
5mV/cm - 20 V/cm.
Waveform measurements.
* R1072_ Digital Multimeter AC/DC voltage and current
measurements.
* R1377_ AC Voltmeter 100µV to 300V, 5Hz -
1MHz, 10Mohm input
impedance.
Audio voltage measurements.
