Motorola GP series Detailed Service Manual

3-74 UHF2 PCB 8415235H01 Parts List
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C282 NOTPLACED -
C283 NOTPLACED -
C285 2113944A40 CAP CER CHP 100.0PF 50V
5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
C289 2113944A40 CAP CER CHP 100.0PF 50V
5%
C291 2313960M51 CAP TANT 10 UF 10% 6.3V
2012-12
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98 CAP,FXD,.47UF,+10%,-
10%,50V-DC,080
C294 2113944A40 CAP CER CHP 100.0PF 50V
5%
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02 CAP CER CHP 10,000PF 25V
10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A23 CAP CER CHP 8.2PF 50V +/-
0.5PF
C302 2113944A26 CAP CER CHP 12.0PF 50V
5%
C303 2113944C21 CAP CER CHP 4.3PF 50V +/-
0.25PF
C304 2113944A77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C
C305 2113944A40 CAP CER CHP 100.0PF 50V
5%
C306 NOTPLACED -
C307 2113944A40 CAP CER CHP 100.0PF 50V
5%
C308 2113944A40 CAP CER CHP 100.0PF 50V
5%
C309 2113944A40 CAP CER CHP 100.0PF 50V
5%
C310 2113944A40 CAP CER CHP 100.0PF 50V
5%
C311 NOTPLACED -
C312 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C313 2113944A77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40 CAP CER CHP 100.0PF 50V
5%
C316 2113944C21 CAP CER CHP 4.3PF 50V +/-
0.25PF
Circuit
Ref
Motorola
Part No.
Description
C317 2113944A73 CAP,FXD,8PF,.5PF+/-,50V-
DC,0402,C
C318 2113944A26 CAP CER CHP 12.0PF 50V
5%
C319 2113944A16 CAP CER CHP 4.3PF 50V +/-
0.25PF
C320 2113944A24 CAP CER CHP 9.1PF 50V +/-
0.5PF
C321 2113944A40 CAP CER CHP 100.0PF 50V
5%
C322 2113944A38 CAP CER CHP 82.0PF 50V
5%
C324 2115153H40 CAP, CERAMIC, COG
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C328 2113946K02 CAP CER CHP 0.10UF 16V
C329 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13 CAP CER CHP 4700PF 50V
10%
C337 NOTPLACED -
C338 NOTPLACED -
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945D04 CAP CER CHP 100,000PF
25V 10%
C345 2113946K02 CAP CER CHP 0.10UF 16V
C346 2113946K02 CAP CER CHP 0.10UF 16V
C347 2113946K02 CAP CER CHP 0.10UF 16V
C348 2113946K02 CAP CER CHP 0.10UF 16V
C349 2113945D04 CAP CER CHP 100,000PF
25V 10%
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41 CAP CER CHP 120.0PF 50V
5%
C352 2113946K02 CAP CER CHP 0.10UF 16V
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C358 NOTPLACED -
C359 NOTPLACED -
C360 2113944A13 CAP CER CHP 3.3PF 50V +/-
0.25PF
C361 2113946K02 CAP CER CHP 0.10UF 16V
C362 2113946K02 CAP CER CHP 0.10UF 16V
C364 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0402,C
C366 NOTPLACED -
C367 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C
C370 2115153H18 CAP, CERAMIC, COG
C371 NOTPLACED -
Circuit
Ref
Motorola
Part No.
Description
C372 2113944A40 CAP CER CHP 100.0PF 50V
5%
C373 NOTPLACED -
C374 2113944A40 CAP CER CHP 100.0PF 50V
5%
C375 2113944A40 CAP CER CHP 100.0PF 50V
5%
C378 NOTPLACED -
C380 2113945B02 CAP CER CHP 10,000PF 25V
10%
C381 NOTPLACED -
C382 2313960B57 CAP,TANTA-
LUM,10UF,+10%,-10%,4V-
DC,S
C383 NOTPLACED -
C385 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0402,C
C386 2113944A40 CAP CER CHP 100.0PF 50V
5%
C390 NOTPLACED -
C400 2113945B02 CAP CER CHP 10,000PF 25V
10%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C402 2113946K02 CAP CER CHP 0.10UF 16V
C403 2113743G24 CAP CHIP 2.2 UF 16V+80-
20%
C404 NOTPLACED -
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C406 NOTPLACED -
C407 2113946B04 CAP CER CHP 0.10UF 10V
10%
C408 2113944A40 CAP CER CHP 100.0PF 50V
5%
C409 2113946K02 CAP CER CHP 0.10UF 16V
C410 2113946B04 CAP CER CHP 0.10UF 10V
10%
C411 2113946K02 CAP CER CHP 0.10UF 16V
C414 2113946K02 CAP CER CHP 0.10UF 16V
C415 2185895Z01 CAPACITOR CER LOW DIST
.01UF
C416 2113946B04 CAP CER CHP 0.10UF 10V
10%
C419 NOTPLACED -
C420 2113945B02 CAP CER CHP 10,000PF 25V
10%
C421 2113946B04 CAP CER CHP 0.10UF 10V
10%
C422 2113946K02 CAP CER CHP 0.10UF 16V
C423 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C424 NOTPLACED -
C425 2113946K02 CAP CER CHP 0.10UF 16V
C426 2113944A40 CAP CER CHP 100.0PF 50V
5%
C427 2113944A40 CAP CER CHP 100.0PF 50V
5%
C428 2113946K02 CAP CER CHP 0.10UF 16V
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946B04 CAP CER CHP 0.10UF 10V
10%
C431 2113944A40 CAP CER CHP 100.0PF 50V
5%
C432 NOTPLACED -
C433 2113945B02 CAP CER CHP 10,000PF 25V
10%
C434 2113946B04 CAP CER CHP 0.10UF 10V
10%
C435 2113946K02 CAP CER CHP 0.10UF 16V
C436 2113944A29 CAP CER CHP 22.0PF 50V
5%
C437 2113944A29 CAP CER CHP 22.0PF 50V
5%
C440 2113946Q01 CAP CER CHP 4.7UF 16V
C441 2113944A40 CAP CER CHP 100.0PF 50V
5%
C442 2113945D04 CAP CER CHP 100,000PF
25V 10%
C443 2113946B04 CAP CER CHP 0.10UF 10V
10%
C444 2113944A40 CAP CER CHP 100.0PF 50V
5%
C445 2113944A40 CAP CER CHP 100.0PF 50V
5%
C447 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C448 2113946B04 CAP CER CHP 0.10UF 10V
10%
C449 2113944A40 CAP CER CHP 100.0PF 50V
5%
C450 NOTPLACED -
C451 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C452 2113743B29 CAP CHIP 1.00 UF 10% 16V
C453 2113944A40 CAP CER CHP 100.0PF 50V
5%
C456 2113944A40 CAP CER CHP 100.0PF 50V
5%
C458 2113944A40 CAP CER CHP 100.0PF 50V
5%
C459 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
