Frequency Generation Circuit 1-9
In the receive mode, U250 pin 19 is low or grounded. This activates the receive VCO by enabling
the receive oscillator and the receive buffer of U250. The RF signal at U250 pin 8 is run through an
injection amplifier, Q304. The resulting RF signal is the LO RF INJECTION and it is applied to the
mixer at U301 (refer to Figure 3-88: 800MHz Receiver Front End Schematic Diagram).
During the transmit condition, when PTT is depressed, five volts is applied to U250 pin 19. This
activates the transmit VCO by enabling the transmit oscillator and the transmit buffer of U250. The
RF signal at U250 pin 10 is amplified by Q251 and injected into the input of the PA module (U101
pin1). This RF signal is the TX RF INJECTION. Also in transmit mode, the audio signal to be
frequency modulated onto the carrier is received through the U201 pin 41.
When a high impedance is applied to U250 pin19, the VCO is operating in BATTERY SAVER mode.
In this case, both the receive and transmit oscillators as well as the receive transmit and prescaler
buffer are turned off.
4.3 Trunked Radio Systems
Trunked systems allow a large number of users to share a relatively small number of frequencies or
repeaters without interfering with each other. The airtime of all the repeaters in a trunked system is
pooled, which maximizes the amount of airtime available to any one radio and minimizes channel
congestion. A benefit of trunking is that the user is not required to monitor the system before
transmitting.
4.3.1 Privacy Plus Trunked Systems
Privacy Plus is a proprietary trunking protocol developed by Motorola which allows a large number
of users to share small amounts of frequencies without interfering with each other. The Privacy Plus
configuration consists of shared multiple channel repeaters. The Privacy Plus Trunked system
includes a Central Controller, which directs the users to the open channels. This kind of Trunked
system requires no monitoring of the channel as in conventional systems. The Central Controller
places the user in a queue to wait for a free channel. The Central Controller does the monitoring and
channels selection for the user.
4.3.2 LTR
™
Trunked Systems
LTR is a transmission based trunking protocol developed by the E. F. Johnson Company for
primarily single site trunking applications. In transmission trunking, a repeater is used for only the
duration of a single transmission. Once a transmission is completed, that repeater becomes
available to other users.
Desired Mode AUX 4 AUX 3 TRB
Tx Low High (@3.2V) High (@4.8V)
Rx High Low Low
Battery Saver Low Low Hi-Z/Float (@2.5V)
Table 1-1 Level Shifter Logic
