UHF2 PCB 8415235H05 Parts List 3-79
14.0 UHF2 PCB 8415235H05 Parts List
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 CONNECTOR (CONTACT
BATTERY)
B503 3980502Z01 CONTACT, BACKUP B+
B504 3980501Z01 CONTACT, BACKUP B-
C101 2113944C45 CAP CER CHP 100.0PF
50V 5%
C102 2113944C27 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C103 2113944C78 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C104 2113944C27 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C105 2113944A40 CAP CER CHP 100.0PF
50V 5%
C106 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C107 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C108 2113944A40 CAP CER CHP 100.0PF
50V 5%
C109 2113944C45 CAP CER CHP 100.0PF
50V 5%
C110 2113944A40 CAP CER CHP 100.0PF
50V 5%
C111 2115938H01 CAP CHIP CL1 11.0 +/-0.05
PF
C112 2115937H03 HIGH Q CHIP CAPACI-
TOR, 33PF
C113 2115937H02 HIGH Q CHIP CAPACI-
TOR, 15PF
C114 2113944A40 CAP CER CHP 100.0PF
50V 5%
C115 2113944A79 CAP,FXD,16PF,+5%,-
5%,50V-DC,0402,C
C116 2113944A77 CAP,FXD,11PF,+5%,-
5%,50V-DC,0402,C
C117 NOT-
PLACED
-
C118 2113944A40 CAP CER CHP 100.0PF
50V 5%
C119 2113944A40 CAP CER CHP 100.0PF
50V 5%
C120 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C121 2113944A40 CAP CER CHP 100.0PF
50V 5%
C122 2113944A40 CAP CER CHP 100.0PF
50V 5%
C123 2313960F04 CAP TANT 33 UF 10% 16V
6032-28
C125 2113944A40 CAP CER CHP 100.0PF
50V 5%
C126 2113946K02 CAP CER CHP 0.10UF 16V
C127 2113945A09 CAP CER CHP 1000PF
50V 10%
C128 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C129 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C130 2113944A40 CAP CER CHP 100.0PF
50V 5%
C131 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C132 2113944A40 CAP CER CHP 100.0PF
50V 5%
C133 2113945A09 CAP CER CHP 1000PF
50V 10%
C134 2113945A12 CAP CER CHP 3300PF
50V 10%
C135 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
Circuit
Ref
Motorola
Part No.
Description
C138 2113944A40 CAP CER CHP 100.0PF
50V 5%
C140 0613952H91 CER CHIP RES 5600 OHM
5% 0603
C141 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C150 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C151 2113944A40 CAP CER CHP 100.0PF
50V 5%
C152 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C160 2113944A34 CAP CER CHP 56.0PF 50V
5%
C161 2113946K02 CAP CER CHP 0.10UF 16V
C165 2113944A34 CAP CER CHP 56.0PF 50V
5%
C166 2113944A40 CAP CER CHP 100.0PF
50V 5%
C169 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C170 2113944A40 CAP CER CHP 100.0PF
50V 5%
C171 2113944A40 CAP CER CHP 100.0PF
50V 5%
C172 2113945D04 CAP CER CHP 100,000PF
25V 10%
C173 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C174 2113944A40 CAP CER CHP 100.0PF
50V 5%
C180 NOT-
PLACED
-
C181 NOT-
PLACED
-
C188 2113944A83 CAP,FXD,36PF,+5%,-
5%,50V-DC,0402,C
Circuit
Ref
Motorola
Part No.
Description
C201 2113944A40 CAP CER CHP 100.0PF
50V 5%
C202 2113945A09 CAP CER CHP 1000PF
50V 10%
C203 2313960B30 CAP TANT 4.7 UF 10% 10V
3216-18
C204 2113946N03 CAP CER CHP 2.2UF 16V
C206 2113944C04 CAP CER CHP 330.0PF
50V 5%
C207 2113944A32 CAP CER CHP 39.0PF 50V
5%
C208 NOT-
PLACED
-
C210 2113944A40 CAP CER CHP 100.0PF
50V 5%
C211 2113944A40 CAP CER CHP 100.0PF
50V 5%
C212 2113944A40 CAP CER CHP 100.0PF
50V 5%
C213 2113944A40 CAP CER CHP 100.0PF
50V 5%
C214 2113944A40 CAP CER CHP 100.0PF
50V 5%
C217 2113946N03 CAP CER CHP 2.2UF 16V
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2113946L03 CAP CER CHP 0.22UF 16V
C220 2113944A40 CAP CER CHP 100.0PF
50V 5%
C223 2113946K02 CAP CER CHP 0.10UF 16V
C224 2113946K02 CAP CER CHP 0.10UF 16V
C228 2313960D05 CAP TANT 4.7 UF 10% 16V
3528-21
C229 2113945A09 CAP CER CHP 1000PF
50V 10%
C230 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
