Motorola GP series Detailed Service Manual

PCB/Schematic Diagrams and Parts List: Keypad 2-15
3.6 PCB 8480574Z05 - Parts List
Circuit Ref
Motorola
Part No.
Description
C610 2113743N50 100 pF
C611 2113743N50 100 pF
C612 2113743N50 100 pF
C613 2113743N50 100 pF
C615 2113743N50 100 pF
C616 2113743N50 100 pF
C618 2113743N50 100 pF
C619 2113743N50 100 pF
C620 2113743N50 100 pF
C621 2113743N50 100 pF
C622 2113743N50 100 pF
C631 2113743N50 100 pF
C630 2113743N43 51 pF
C632 2113743N43 51 pF
C633 2113743N50 100 pF
C634 2113743N43 51 pF
C635 2113743N50 100 pF
C636 2113743N43 51 pF
C637 2113743N50 100 pF
C638 2113743N43 51 pF
C639 2113743N50 100 pF
C640 2113743N43 51 pF
C641 2113743N50 100 pF
C642 2113743N43 51 pF
C643 2113743N50 100 pF
C644 2113743N43 51 pF
C645 2113743N50 100 pF
C646 2113743N50 100 pF
C647 2113743N43 51 pF
D601 4880479U01 79U01
D602 4880479U01 79U01
D603 4880479U01 79U01
D604 4880479U01 79U01
D605 4880479U01 79U01
D606 4880479U01 79U01
E634 2480640Z01 Ind Bead
E637 2480640Z01 Ind Bead
E638 2480640Z01 Ind Bead
E639 2480640Z01 Ind Bead
E640 2480640Z01 Ind Bead
E641 2480640Z01 Ind Bead
E642 2480640Z01 Ind Bead
E643 2480640Z01 Ind Bead
E644 2480640Z01 Ind Bead
E645 2480640Z01 Ind Bead
J601 0980521Z01 44 pin connector
J602 0905505Y03 18 pin connector
Q601 4805128M67 MMBT3906
transistor (PNP)
Q602 4880214G02 MMBT3904
transistor (NPN)
Q603 4880214G02 MMBT3904
transistor (NPN)
R601 0662057V20 51K
R602 0662057V20 51K
R603 0662057V05 13K
R604 0662057V11 22K
R605 0662057V18 43K
R606 0662057V30 130K
R607 0662057V05 13K
R608 0662057V11 22K
R609 0662057V18 43K
R610 0662057V30 130K
R611 0662057N16 51K
R612 0662057N41 560K
R613 0662057N47 1M
R614 0662057M01 0 ohm
R617 0662057M01 0 ohm
R618 0662057M74 1K
R619 0662057M74 1K
R620 0662057M74 1K
R621 0662057M74 1K
R622 0662057M74 1K
R623 0662057M74 1K
R626 0662057M01 0 ohm
R627 0662057M01 0 ohm
R631 0662057M01 0 ohm
R632 0662057N23 100K
R633 0662057N23 100K
R646 0662057N23 100K
R647 0662057M85 3K
R648 0662057N23 100K
R649 0662057N15 47K
U602 5102463J49 LMC7211
comparator
8480574Z05 PC Board
Circuit Ref
Motorola
Part No.
Description
