UHF PCB 8415234H08 Parts List 3-137
21.0 UHF PCB 8415234H08 Parts List
Circuit
Ref
Motorola
Part No.
Description
8415234H05 PC BOARD, UHF BAND 1
B501 0986237A02 CONNECTOR (CONTACT
BATTERY)
B503 3980502Z01 CONTACT, BACKUP B+
B504 3980501Z01 CONTACT, BACKUP B-
C101 2113944C45 CAP CER CHP 100.0PF
50V 5%
C102 2113944M16 CAP,FXD,8.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C103 2113944M21 CAP,FXD,13PF,,+2%,-
2%,50V-DC,0603,C
C104 2113944M15 CAP,FXD,7.5PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C105 2113944A40 CAP CER CHP 100.0PF
50V 5%
C106 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25
C107 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25
C108 2113944A40 CAP CER CHP 100.0PF
50V 5%
C109 2113944C45 CAP CER CHP 100.0PF
50V 5%
C110 2113944A40 CAP CER CHP 100.0PF
50V 5%
C111 2113944C32 CAP CER CHP 15.0PF 50V
5%
C112 2115937H04 HIGH Q CHIP CAPACITOR,
47PF
C113 2115937H01 HIGH Q CHIP CAPACITOR,
10PF
C114 2113944A40 CAP CER CHP 100.0PF
50V 5%
C115 2113944A81 CAP,FXD,24PF,+5%,-
5%,50V-DC,04
C116 2113944A81 CAP,FXD,24PF,+5%,-
5%,50V-DC,04
C117 2113944A29 CAP CER CHP 22.0PF 50V
5%
C118 2113944A40 CAP CER CHP 100.0PF
50V 5%
C119 2113944A40 CAP CER CHP 100.0PF
50V 5%
C120 2113944A77 CAP,FXD,11PF,+5%,-
5%,50V-DC,04
C121 2113944A40 CAP CER CHP 100.0PF
50V 5%
C122 2113944A40 CAP CER CHP 100.0PF
50V 5%
C123 2313960F04 CAP TANT 33 UF 10% 16V
6032-28
C125 2113944A40 CAP CER CHP 100.0PF
50V 5%
C126 2113946K02 CAP CER CHP 0.10UF 16V
C127 2113945A09 CAP CER CHP 1000PF
50V 10%
C128 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C129 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5P
C130 2113944A40 CAP CER CHP 100.0PF
50V 5%
C131 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C133 2113945A09 CAP CER CHP 1000PF
50V 10%
C134 2113945A12 CAP CER CHP 3300PF
50V 10%
C135 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
Circuit
Ref
Motorola
Part No.
Description
C138 2113944A40 CAP CER CHP 100.0PF
50V 5%
C140 0613952H91 CER CHIP RES 5600 OHM
5 0603
C141 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C150 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C151 2113944A40 CAP CER CHP 100.0PF
50V 5%
C152 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C160 2113944A40 CAP CER CHP 100.0PF
50V 5%
C161 2113946K02 CAP CER CHP 0.10UF 16V
C165 2113944A40 CAP CER CHP 100.0PF
50V 5%
C166 2113944A40 CAP CER CHP 100.0PF
50V 5%
C169 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5P
C170 2113944A40 CAP CER CHP 100.0PF
50V 5%
C171 2113944A40 CAP CER CHP 100.0PF
50V 5%
C172 2113944C45 CAP CER CHP 100.0PF
50V 5%
C173 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C174 2113944A40 CAP CER CHP 100.0PF
50V 5%
C175 2113944C45 CAP CER CHP 100.0PF
50V 5%
C201 2113944A40 CAP CER CHP 100.0PF
50V 5%
C202 2113945A09 CAP CER CHP 1000PF
50V 10%
Circuit
Ref
Motorola
Part No.
Description
C203 2113946H01 CAP CER CHP 4.7UF 10V
10%
C204 2113946N03 CAP CER CHP 2.2UF 16V
C206 2113944C04 CAP CER CHP 330.0PF
50V 5%
C207 2113944A33 CAP CER CHP 47.0PF 50V
5%
C208 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C210 2113944A40 CAP CER CHP 100.0PF
50V 5%
C211 2113944A40 CAP CER CHP 100.0PF
50V 5%
C212 2113944A40 CAP CER CHP 100.0PF
50V 5%
C213 2113944A40 CAP CER CHP 100.0PF
50V 5%
C214 2113944A40 CAP CER CHP 100.0PF
50V 5%
C217 2113946N03 CAP CER CHP 2.2UF 16V
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2113946L03 CAP CER CHP 0.22UF 16V
C220 2113944A40 CAP CER CHP 100.0PF
50V 5%
C223 2113946K02 CAP CER CHP 0.10UF 16V
C224 2113946K02 CAP CER CHP 0.10UF 16V
C228 2313960D05 CAP,FXD,4.7UF,+10%,-
10%,16V-DC
C229 2113945A09 CAP CER CHP 1000PF
50V 10%
C230 2113944A40 CAP CER CHP 100.0PF
50V 5%
C231 2113946K02 CAP CER CHP 0.10UF 16V
C232 2113945D02 CAP CER CHP 47,000PF
25V 10%
Circuit
Ref
Motorola
Part No.
Description
