Motorola MG7550 User Manual





To configure and enable a Guest Network on the 5 GHz band, first select the
5 GHz tab, and then repeat the steps above.

NetworkNamecanbefrom6‐32characterslong.Youcanusetheupperandlower
caseletters(a–zandA–Z),numbers(0‐9)andspecialcharacters(e.g.$_/&etc.)
exceptthesinglequote‘.

Passwordcanbefrom8‐63characterslong.Youcanuseupperandlowercaseletters
(a–zandA–Z),numbers(0‐9)andspecialcharacters(e.g.$_/&etc.)exceptthesingle
quote‘.

Changing Firewall Settings
A Firewall helps protect your Model MG7550 and the devices attached to it
from harm from outsiders connecting via the Internet. Model MG7550
comes with reasonable firewall settings. The firewall allows all normal traffic
to pass, but protects against well-known attacks. Normally you just leave the
firewall settings in place. If you want to change them, you go to the
ProtectionÆFirewall section of the Configuration Manager. First log into the
Configuration Manager as described in chapter 6. In summary, you type
192.168.0.1 in the address bar of your browser, go to that address, enter the
Username admin and Password motorola, then click the Login button.
This will bring you to the Basic Status and Settings page. Click the Advanced
button in the upper right. This will bring you to the Status Æ Software page.
Hover over the Protection & Parental Control menu item, and select the
Firewall submenu.





Motorola MG7550 Specifications

General

Type	Cable Modem
DOCSIS	3.0
Channel Bonding	16x4
Max Download Speed	686 Mbps
Max Upload Speed	123 Mbps
Built-in Router	Yes
Wi-Fi Standard	802.11ac
Wi-Fi Bands	Dual-band
Ethernet Ports	4
Phone Ports	0
Wi-Fi Speed	1900 Mbps
Compatibility	XFINITY from Comcast, Cox, Charter Spectrum
