1 - 14 WT41N0 User Guide
Figure 1-18
Splash Screen
Figure 1-19
Start Up Window
Use the Calibration screen to align the touch screen:
1. Carefully press and briefly hold on the center of the Calibration screen target. Repeat the procedure as
the target moves and stops at different locations on the screen. This enters the new calibration settings.
Figure 1-20
Calibration Screen
2. Once all of the new calibration settings are input, tap the screen or press the ENTER button to save the
new calibration settings. Press ESC to discard the new calibration settings.
Voice Only WT41N0 Boot Up
When the Voice Only WT41N0 is powered on for the first time the three LEDs on the front housing blink as
follows:
1. Application Controlled LED and Battery Status LED on.
2. All LEDs Off.
3. Application Controlled LED on, Battery Status LED on, WLAN Status LED on.
Calibration Screen Confirm Calibration
Screen
