English-45
English
SLOT2 CH SETTING Selects signal type according to the slot 2 type option specifications.
AUTO Sets the signal type automatically.
1CH Fills the screen entirely with the signal which is selected in SLOT2 CH SELECT.
2CH The DisplayPort signal is displayed on the left half of the screen, the TMDS signal is displayed on the right
half. If
the internal PC does not support either one of the signal types, the existing signal will automatically be
displayed on the full screen.
SLOT2 CH SELECT This function is available only when SLOT2 CH SETTING is 1CH.
DisplayPort Shows the DisplayPort signal from a slot 2 type PC option on the full screen.
TMDS Shows the TMDS signal from a slot 2 type PC option on the full screen.
RESET Resets the AUDIO setting back to the factory setting within the OPTION menu.
SYSTEM
MONITOR INFORMATION Shows the model name, serial number and firmware version of your monitor.
CARBON SAVINGS: Display the estimated carbon saving information in kg-CO2. The carbon footprint factor in
the carbon saving calculation is based on the OECD (2008 Edition).
CARBON USAGE: Display the estimated carbon usage information in kg-CO2. This is the arithmetic estimation,
not actual measurement value. This estimation is based without any options.
FIRMWARE Displays firmware version that is installed to the monitor.
MAC ADDRESS Displays the MAC ADDRESS.
FACTORY RESET All items are returned to factory shipment state.
NOTE: You can reset all items in all daisy chained monitors. Please be careful to avoid resetting all items
inadvertently.
Default values can be provided on request.
