NETGEAR C6220 User Manual

Supplemental Information
101
AC1200 WiFi Cable Modem Router Model C6220
Factory Default Settings
You can return the modem router to its factory default settings.
 To restore the factory default settings:
1. Locate the Reset button on the rear panel of the modem router
.
2. Use a paperclip or sharp object to press and hold the Reset button for over seven seconds.
Reset button
The modem router resets and returns to the factory settings shown in the following table.
Table 4. Factory Settings
Feature Default Setting
Gateway login User login URL http://192.168.0.1
User name and password
(case-sensitive)
admin / password
Local network
(LAN)
LAN IP 192.168.0.1
Subnet mask 255.255.255.0
DHCP server Enabled
DHCP starting IP address 192.168.0.2
DHCP ending IP address 192.168.0.254
Firewall Inbound communication from the
Internet
Disabled (except traffic on port 80, the HTTP port)
Outbound communication to the
Internet
Enabled (all)
Source MAC filtering Disabled
Internet
connection
WAN MAC address Use default hardware address

NETGEAR C6220 Specifications

General

Product type	Tabletop router
Product color	Black
LED indicators	Power
USB port	Yes
Memory card slot(s)	No
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	12 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	340 Mbit/s
Certification	CableLabs
Processor frequency	1600 MHz
Cables included	LAN (RJ-45)
Power source type	AC
Security algorithms	WPA2, WPA2-AES

Weight and Dimensions

Depth	155 mm
Width	235 mm
Height	57 mm
Weight	440 g
