SECTION 3 -- FIELD OPERATIONS
3--56
WARNING
Do not use ballast systems other than those
indicated.
Do not ballast the tractor unnecessarily; not only is
it superfluous, it can also damage the tractor.
WARNING
With mounted implements fitted to the rear of the
tractor, it is a good idea to fit a minimum 20% extra
weight on the front axle.
STATIC WEIGHT DISTRIBUTION ON THE TRACTOR -- Fig. 61
Add or remove ballast from the tractor once it is fully
equipped, until a balanced static weight distribution
is achieved for the implement actually used, taking
care not to exceed the maximum operating weights
given on page 3--55.
The weight distribution percentages given for the
four--wheel drive models are indicative only and
relate to the total weight of the fully equipped tractor
complete with ballast.
FOUR WHEEL DRIVE MODELS
TRE0031A
61
REAR AXLE FRONT AXLE
60% 40%
