SECTION 2 -- CONTROLS, INSTRUMENTS AND OPERATION
2--2
SAFETY COVERS AND GUARDS
The tractor is fitted with covers and guards for the
personal safety of the operator and other people
when working.
CAUTION
Before starting the engine or using the tractor ,
always check that all safety covers and guards are
correctly fitted.
BONNET (HOOD) -- Fig. 1
The hood (1) covers the engine’s moving parts.
It must be closed before the engine is started and the
tractor is used.
1
1
FAN GUARD -- Fig. 2
Both sides of the fan have guards (1). The guard
shown protects the left--hand side of the fan.
TRE0022A
1
2
STARTER MOTOR COVER -- Fig. 3
The cover (1) protects the electro--magnetic
contacts of the starter motor from accidental contact.
It must always be in place when the batteries are
connected to the electrical system.
The cover also protects the battery from possible
damage and the electrical connections from possible
accidental contact.
TRE0070A
1
3
