SECTION 8 -- SPECIFICATIONS
8--9
Maximum lift capacity
With lift rods located in rear holes of horizontal arms and upper hole of top link attachment bracket :
Model
TD 60D TD 70D TD 80D TD 90D TD 95D
at link ends of horizontal arms
(kg)
3000 3565
with center of gravity at 610 mm
(24 in) from link ends (kg)
2260 2700
THREE--POINT LINKAGE
Category I and Category II three--point linkage device.
Stabilizer device :
-- telescopic stabilizers (standard).
Single or double--acting rear remote control valves: up to three, one with float and automatic release.
FRONT AXLE
Central pivoting, telescopic, inverted ”U” structure.
T rack adjustment : by extending the axle.
FRONT WHEELS 2WD
Rims with integral steel wheel discs.
FRONT WHEELS 4WD
Wheels in two parts : steel wheel disc and rim.
T rack adjustment : by interchanging rims to discs and to wheel hubs.
REAR WHEELS
Wheels in two parts : steel wheel disc and rim.
T rack adjustment : by interchanging rims to discs and to wheel hubs.
NOTE: Tyre specifications are shown on pages
between 3--41 and 3--54.
