SECTION 2 -- CONTROLS, INSTRUMENTS AND OPERATION

2--5

INSTRUMENT PANEL

3 4

TRE0027A

1. Warning and indicator lights

These lights illuminate to indicate a particular

operation or to attract your attention.

2. Engine coolant temperature gauge

3. Proofmeter / tachometer

Hourmeter, engine speed counter, tachometer .

4. Fuel gauge
