SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--15
INTERNATIONAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilised on the instruments,
controls, switches, and fuse box. The symbols are shown below with an indication of their meaning.
Headlamp
dipped beam
Stop
lamps
Thermostart
starting aid
Alternator
charge
Fuel level
Engine speed
(rev/min x 100)
Hours recorded
Engine oil
pressure
Engine coolant
temperature
Tractor lights
Headlamp
main beam
Work lamps
Automatic
fuel shut-off
Coolant
level
Turn signals
Turn signals
--one trailer
Turn signals
--two trailers
Heater fan
Front wind-
screen
wash/wipe
Air filter
blocked
Parking
brake
Rear
windscreen
wash/wipe
Horn
Roof
beacon
Radio
Keep alive
memory
Heater
temperature
control
Air conditioner
Warning!
Warning!
Corrosive
substance
P. T. O .
Transmission
in neutral
Creeper
gears
Slow or
low setting
Fast or high
setting
Ground
speed
FWD
engaged
FWD
disengaged
Variable
control
Differential
lock
Rear axle oil
temperature
Transmission
oil pressure
Pressuri sed!
Open carefully
Malfunction!
See Operator’s
Manual
Position
Control
Draft
Control
Hitch dis-
abled
% slippage
Hitch raise
(rear)
Hitch lower
(rear)
Hitch height
limit (rear)
Remote
valve extend
Remote
valve retract
Remote
valve float
Hydraulic and
transmission
filters
Accessory
socket
Implement
socket
Hazard
warning lights
KAM
N
Malfunction!
(alternative
symbol )
T railer
brake
Hitch height
limit (front)
Brake fluid
level
