SECTION 2 -- CONTROLS, INSTRUMENTS AND OPERATION
2--4
CONTROLS AND INSTRUMENTS -- POSITION AND FUNCTION
The position and function of the controls and
instruments on your tractor are described in the
following pages.
The controls have been sub--divided into groups and
are described as follows:
-- Instrument panel and console controls
-- Instrument console (rear hood) controls
-- Operating controls, right--hand side.
-- Operating controls, left--hand side.
-- Foot pedal and foot plate controls.
-- Cab controls.
CAUTION
Do not use the tractor if you are not fully acquainted
with the position and operation of all the tractor
controls.
