B710, B720, B730 User’s Guide > 13
Control Panel Buttons
No. Button Description
1
<Enter> Print mode: press to enter the menu mode.
Menu mode: press to select the currently displayed menu
item.
2
Up Arrow Print mode: press to enter the menu mode.
Menu mode: Press to navigate up in the menu screen
listings
3
<Back> Menu mode: press to go up one level in the menu, or press
repeatedly to exit the menu.
4
Down Arrow Menu mode: press to navigate down in the menu screen
listings.
5
<On Line> Press to switch back and forth between on-line (Ready to
Print) and Off-line status. When Off-line, the machine
cannot receive data or process printing.
6
<Cancel> Print mode: press to cancel printing.
Menu mode: press to exit Menu Mode.
7
<Help> Press for more information regarding error messages on
line 5 of the display.
8
Keypad, for making alphanumeric entries.
WXYZTUVPQRS
MNOJKLGHI
DEFABC
Menu
Back
Enter
On Line
Cancel
Help
#
9
6
3
1
4
7
*
0
8
5
2
WXYZTUVPQRS
MNOJKLGHI
DEFABC
