Advanced network settings > 84
Printer
Reboot 1-5
TCP #1-5
Printer
Reboot
Trap
- - - Disable Specifies whether to send an
SNMP message when the
machine has rebooted.
Receive
Illegal
Packet 1-5
TCP #1-5
Receive
Illegal Trap
- - - Disable Specifies whether to use a trap
when a community name other
than the one set in Printer Trap
Community Name is used to
access the machine.
Online 1-5 TCP #1-5
Online
Trap
- - - Disable Specifies whether to send an
SNMP message every time the
machine comes online.
Offline 1-5 TCP #1-5
Offline
Trap
- - - Disable Specifies whether to send an
SNMP message every time the
machine goes offline.
Paper Out
1-5
TCP #1-5
Paper Out
Trap
- - - Disable Specifies whether to send an
SNMP message when the
machine runs out of paper.
Paper Jam
1-5
TCP #1-5
Paper Jam
Trap
- - - Disable Specifies whether to send an
SNMP message when the paper
jams.
Cover
Open 1-5
TCP #1-5
Cover
Open Trap
- - - Disable Specifies whether to send an
SNMP message every time the
machine’s cover opens.
Printer
Error 1-5
TCP #1-5
Printer
Error Trap
- - - Disable Specifies whether to send an
SNMP message when an error
occurs.
IPX IPX Trap
Address/
Net
- - - 000000000
000;
00000000
Specifies a trap destination in
IPX. Specify the value as
“(network address):(node
address)”. You can specify only
one address.
IPX Trap
Enable
IPX Trap
Enable
- - - Disable Specifies whether to use a
printer trap in IPX.
IPX Printer
Reboot
- - - - Disable Specifies whether to send an
SNMP message when the
machine has rebooted.
IPX
Receive
Illegal
Packet
- - - - Disable Specifies whether to use a trap
when a community name other
than the one set in Printer Trap
Community Name is used to
access the machine.
IPX Online IPX Online
Trap
- - - Disable Specifies whether to send an
SNMP message every time the
machine comes online.
IPX Offline IPX Offline
Trap
- - - Disable Specifies whether to send an
SNMP message every time the
machine goes offline.
ITEM DEFAULT
VALUE
DESCRIPTION
WEB
PAGE
TELNET CONFIG.
TOOL
NETWORK
SETTING
PLUG-IN
NETWORK CARD
SETUP
(WIN.) (MAC)
