SETTING UP YOUR PRINTER > 21
TOP FEED SINGLE SHEET PAPER
Your printer can accommodate single sheets of 216mm width x 297 or
355mm length paper. Remove the Tractor Feed unit and any other
accessories, then raise the Paper Separator into its upright position.
1. Switch the printer ON.
2. Move the Paper lever (1) (on the right-hand side of the printer)
to the rear of the machine, to the Blank sheet of paper symbol.
3. Ensure that the printer is OFF-LINE (press the SELECT switch if
necessary).
Make sure the Bail arm lever (2) is set to the rear of the machine
(in its closed position).
4. Raise the paper separator as shown above.
5. Adjust the Cut Sheet guide (3) on the Paper Separator to
position the left edge of the sheet.
NOTE
If letter size paper is used, set the cut sheet guide to the line mark on the
paper separator. 80 character width text (10cpi) is then positioned
centrally on the paper.
1
2
3

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
