Oki ML280 Elite User Manual

OPERATING YOUR PRINTER > 33
U
SING THE
C
UT
-
SHEET
F
EEDER
(
IF FITTED
)
1. Place the paper set lever (1) in the RESET position.
2. Release the paper guides by pushing the locking levers
downward.
3. Move the left paper guide (2) to the position where you wish to
set the left-hand edge of the sheet, making sure that this
paper guide is not set to the right of the paper out sensor (the
groove in the platen).
4. “Flex” a paper stack (not more than 170 sheets of 60g/m²
(
16lb.) paper
).
Square the stack, turn over and repeat the
bending. The stack of paper should not exceed 16mm
thickness.
1. Paper set lever
2. Left paper guide
3. Rear sheet support
4. Front sheet support
5. Right paper guide
6. Front sheet guide
1
2
3
4
5
6

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
