Oki ML280 Elite User Manual

SETTING UP YOUR PRINTER > 24
USB CONNECTION
l Requires a USB 1.1 cable, maximum length 19.7 ft. (5 m), not
supplied.
l Printer has a USB series “B” receptacle.
1. Attach a suitable USB cable to the printer. Then attach the
cable to your computer.
2. If you have turned the computer and printer OFF, turn them
back ON.
Follow any on-screen insructions.
NOTES
l
For connection to a PC running Windows 98 or above (not Windows
95 upgraded to Windows 98).
l
The operation of a printer is not assured if a USB compatible device is
connected concurrently with other USB-compatible machines.
l
When connecting multiple printers of the same type, they appear as
*****, ***** (2), ***** (3), etc. These numbers depend on the order
of connecting or turning on each printer.
l
USB is a “hot-pluggable” protocol. This means that the printer and
computer do not necessarily have to be switched OFF.

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
