Oki ML280 Elite User Manual

SPECIFICATIONS > 47
SPECIFICATIONS
Item Specification
Print Method
Printhead
Emulations (co-resident)
Print Speed
High Speed Draft (HSD)
Utility (UTL)
Near Letter Quality (NLQ)
Impact dot matrix
9 pins, 0.30 mm (0.0118") diameter, with
thermal protection
Epson FX
IBM Graphics
Oki MICROLINE
333cps*
250cps*
62.5cps*
* cps = characters per second
Paper Specifications
Type Feed Weight Width (range)
Cut Sheets Top only 16 to 21lb. (60 to 81g/m²)
Single part Continuous Rear/Bottom 14 to 20lb. (53 to 75g/m²) 3 to 9.5 inches
Multi Part Continuous Rear/Bottom 14 to 20lb. (53 to 75g/m²) 3 to 9.5 inches
Maximum thickness 0.28mm (0.11 inches)
Maximum number of
sheets
4 (original plus 3 copies) carbonless
Reliability
Ribbon Life (black)
Printhead Life
Mean Time Between
Failures (MTBF)
Mean Time to Repair
(MTTR)
3 million characters, on average
200 million characters average in 10cpi utility mode
20,000 hours at 25% duty cycle and 35% page density
15 minutes
General Printer Characteristics
Dimensions Height: 80mm (height) x 372mm (width) x 275mm (depth)
Weight 4.5Kg
Buffer size 128Kb
Noise level <54dBA and <51dBA in Quiet Mode
Power requirements AC - 230VAC (+6%;-14%), 240VAC (±10%;) @50/60Hz (±2%)
DC - 9.6VDC <-> 31.2VDC, 4.0 <-> 1.8A

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
