Oki ML280 Elite User Manual

SETTING UP YOUR PRINTER > 25
SERIAL CONNECTION
The Serial Interface Board is an option on this printer and is supplied
with installation and setup instructions.
1. Switch both the computer and the printer OFF.
2. Plug the cable into the serial ports of both your PC and printer
and tighten the thumbscrews (1).
The cable should comply with the RS232C Serial Interface
Specification and have a maximum length of 15 metres (49ft).
3. Turn the printer and computer back ON.
CAUTION!
Make sure the printer and computer are both turned OFF.
1

Oki ML280 Elite Specifications

General

Color	No
Character pitch	10, 12, 15, 17.1, 20 cpi
Maximum resolution	240 x 216 DPI
Typestyles supported	Double height, Double width, Emphasised, Enhanced, Italics, Overscore, Underline
Maximum number of copies	3 copies
Maximum print speed (draft)	240 cps
Maximum printing width (columns)	160
Mean time between failures (MTBF)	20000 h
Product color	Gray
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	51 dB
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Serial (RS-232), Serial (RS-422)
AC input voltage	220 - 240 V
Voltage tolerance	10 %
AC input frequency	50 - 60 Hz
Power consumption (typical)	60 W

Weight and Dimensions

Depth	275 mm
Width	372 mm
Height	80 mm
