Page: 55

Service Guide ML390/391

Chapter 3 Maintenance & Disassembly

3.2.12 Indicator Assembly (Bail Bar Assembly)

· Perform these procedures:

3.2.01

,3.2.04 , 3.2.05 , 3.2.06 .

· Use needle-nose pliers to remove the left bail arm spring (1).

· Release the claw (2) and detach the left bail arm (3) from the bail bar (4).

· Pull the left bail arm through the guide hole (5) in the chassis and remove the arm.

· Detach the bail bar from the right bail arm (6).

· Use needle-nose pliers to remove the right bail arm spring (7).

· Release the claw (8) and detach the right bail arm from the bail bar.

· Pull the right bail arm through the guide hole (9) in the chassis and remove the arm.

P/N 50911801 Spring: Bail Arm (L) All RSPL A B C

B.2.04

, B.2.06

P/N 53489301 Bail Arm (L) All RSPL A B C

B.2.04

, B.2.06

P/N 50911701 Spring: Bail Arm (R) All RSPL A B C

B.2.04

, B.2.06

P/N 53489201 Bail Arm (R) All RSPL A B C

B.2.04

, B.2.06

P/N 50061501 Indicator (Assembly) Both 90 RSPL A B C

B.2.04

, B.2.06

P/N 50061502 Indicator (Assembly) Both 91 RSPL A B C

B.2.04

, B.2.06
