Page: 39
Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2 DISASSEMBLY/ASSEMBLY PROCEDURES
General Information
This section contains the printer disassembly procedures. Only the removal procedures are explained.
Reverse the procedure for the installation.
This Service Handbook lists the disassembly procedures for major components of the unit. Okidata does
NOT recommend disassembling a unit which is operating normally. If you decide to perform disassembly
during this training, Okidata recommends that you perform
only
the disassembly procedures for RSPL
items. All other procedures are provided to assist you in identifying parts. It is not likely that you will
perform these procedures while servicing the product.
Read all notes, cautions, and warnings. They contain important information regarding
assembly/disassembly.
At the bottom of each procedure is a listing of the parts covered in that procedure. The Okidata part
number, item description, applicable product, comment (RSPL, Option, Consumable), serial number
revision level, and the cross-reference(s) to Appendix B are provided for each part. Items included in the
Recommended Spare Parts List are indicated by the acronym RSPL. N/A appears where a part number is
not available.
Part Item Product Comment Revision App. B Number Description Reference
Below is an explanation of the terms found in the Product Field of the parts list.
390
This part is found ONLY in the Microline 390 printer.
391
This part is found ONLY in the Microline 391 printer.
390 +
This part is found ONLY in the Microline 390-Plus printer.
391 +
This part is found ONLY in the Microline 391-Plus printer.
Both
This part is found in both the Microline 390 and 391 printers.
Both +
This part is found in both the Microline 390 and 391-Plus printers.
Both 90
This part is found in both the Microline 390 and Microline 390-Plus printers.
Both 91
This part is found in both the Microline 391 and Microline 391-Plus printers.
