Page: 73
Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2.29 Main Chassis Assembly
· All disassembly procedures must be carried out to reach the main chassis assembly (1).
P/N 50061101 Chassis: Main (Assembly) Both 90 RSPL A B C
B.2.05
, B.2.07
P/N 50061201 Chassis: Main (Assembly) Both 91 RSPL A B C
B.2.05
, B.2.07
Copyright 1997, Okidata, Division of OKI America, Inc. All rights reserved. See the OKIDATA Business
Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)
