Getting started > 14
USB
> For connection to a PC running Windows 2000 or above. This port requires a shielded
cable 5m long confirming to USB version 2.0.
Make sure the printer and computer are both turned OFF.
1. Attach a suitable USB cable to the printer. Then attach the cable to your computer.
2. Turn the computer and printer back on.
The following interfaces are available as optional accessories and are described in their
accompanying installation documentation:
> RS-232 C Serial interface
> 100BASE-TX/10BASE-T network connection
NOTE
> Refer to the Network Configuration Guide for setting up the network
connection.
> It is not recommended that you use either the Parallel or USB port when
the RS-232 C or Network Interface option is installed in this printer.
To Next Page
