Olympus E-M5 Mark III User Manual

168 EN
Menu functions (Custom menus)
4
R Disp/8/PC
Option Description
g
Grid Settings Sets the guide line display that appears when shooting.
[Display Color]: Sets the guide line color and opacity. Can
be set to [Preset 1] and [Preset 2].
[Displayed Grid]: Select [w], [x], [y], [X], [
x
] or [1] to
display a grid on the monitor.
[Apply Settings to EVF]: If [On] is selected, the guides
shown in the monitor will also be displayed in the viewfi nder
when [Style 1] or [Style 2] is selected for [EVF Style]. The
setting selected in [EVF Grid Settings] will be invalid.
—
Peaking Settings You can change the edge enhancement color and intensity.
The edge enhancement color (red, yellow, white, black) and
intensity (Standard, Low, High), and the brightness of the
peaking background (On, Off) can be set.
• If [Image Brightness Adj.] is set to [On], the brightness of
live view is adjusted to enhance the enhancement color.
180
Histogram
Settings
[Highlight]: Choose the lower bound for the highlight display.
[Shadow]: Choose the upper bound for the shadow display.
188
Mode Guide Select [On] to display a help for the selected mode when
the mode dial is rotated to a new setting.
34
Selfi e Assist Selecting [On] optimizes the display for self-portraits when
the monitor is in the self-portrait position.
190
S Disp/8/PC
Option Description
g
8 (Beep sound)
When set to [Off], you can turn off the beep sound that is
emitted when the focus locks by pressing the shutter button.
—
HDMI [Output Size]: Selecting the digital video signal format for
connecting to a TV via an HDMI cable.
[HDMI Control]: Select [On] to allow the camera to be
operated using remotes for TVs that support HDMI control.
This option takes effect when pictures are displayed on a
TV.
[Output Frame Rate]: Select the output frame rate from [50p
Priority] or [60p Priority] for using the camera connected to
a TV with an HDMI cable.
191
USB Mode Choose a mode for connecting the camera to a computer.
Choose [Auto] to display USB mode options every time the
camera is connected.
208
MENU
G R
MENU
G S

Olympus E-M5 Mark III Specifications

General

Flip-out screen	-
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	Yes
Display resolution (numeric)	1037000 pixels
Magnification	1.37 x
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Flash modes	Auto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	256000
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLS‑50
Battery life (CIPA standard)	310 shots
Product color	Black
Image editing	Crop, Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Auto, Manual, Program, Scene
Self-timer delay	2, 12 s
Digital zoom	- x
Focal length range	14 - 150 mm
Maximum aperture number	4
Minimum aperture number	5.6
Bluetooth version	4.2
Megapixel	20.4 MP
Camera type	MILC
Sensor type	Live MOS
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888

Weight and Dimensions

Depth	49.7 mm
Width	125.3 mm
Height	85.2 mm
Weight	366 g
Weight (including battery)	414 g
