Olympus E-M5 Mark III User Manual

86 EN
Shooting
2
Reducing camera shake (Image Stabilizer)
You can reduce the amount of camera shake that can occur when shooting in low light
situations or shooting with high magnifi cation.
The image stabilizer starts when you press the shutter button halfway.
1
Press the Q button to display the LV super control
panel.
2
Use FGHI to select the image stabilizer.
3
Use the front dial to select an option.
K Image Stabilizer
1023
1:02:03
sRGB
Natural
S - AF
S
Normal
WB
Auto
ISO
Auto
S-IS AUTO
± 0
A ± 0
± 0.0
±
0 ± 0
± 0
G ± 0
P
250 F5.6
K
Image Stabilizer
30
p
30
p
4K
M-IS
F
n
Image Stabilizer
Still
(S-IS)
S-IS Off Still-I.S. Off
Image stabilization disabled. Select this option when
using a tripod.
S-IS
AUTO
Auto I.S.
Image stabilization applies to motion on all axes.
If panning motion is detected, the camera will
automatically suspend image stabilization on that
axis.
S-IS1
All Direction
Shake I.S.
Image stabilization applies to motion on all axes.
S-IS2
Vertical Shake
I.S.
Image stabilization applies to vertical motion. Use
when panning the camera horizontally.
S-IS3
Horizontal
Shake I.S.
Image stabilization applies to horizontal motion. Use
when panning the camera vertically.
Movie
(M-IS)
M-IS Off Movie-I.S. Off Image stabilizer is off.
M-IS1
All Direction
Shake I.S.
Electronic image stabilization combined with VCM-
controlled image sensor movement.
M-IS2
All Direction
Shake I.S.
VCM-controlled image sensor movement only.
• Image stabilization may be unable to compensate for excessive camera motion or very
slow shutter speeds. Use a tripod in these cases.
• You may notice noise or vibration while image stabilization is in effect.
• The setting selected with the lens image stabilization switch, if any, takes priority over that
selected with the camera.
%
• You can choose whether image stabilization will be performed while the shutter button is
pressed halfway. g [Half Way Rls With IS] (P. 165)
• You can prioritize lens image stabilization. g [Lens I.S. Priority] (P. 165)

Olympus E-M5 Mark III Specifications

General

Flip-out screen	-
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	Yes
Display resolution (numeric)	1037000 pixels
Magnification	1.37 x
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Flash modes	Auto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	256000
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLS‑50
Battery life (CIPA standard)	310 shots
Product color	Black
Image editing	Crop, Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Auto, Manual, Program, Scene
Self-timer delay	2, 12 s
Digital zoom	- x
Focal length range	14 - 150 mm
Maximum aperture number	4
Minimum aperture number	5.6
Bluetooth version	4.2
Megapixel	20.4 MP
Camera type	MILC
Sensor type	Live MOS
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888

Weight and Dimensions

Depth	49.7 mm
Width	125.3 mm
Height	85.2 mm
Weight	366 g
Weight (including battery)	414 g
