Menu functions (Custom menus)
4
Viewing camera images on TV (HDMI)
MENU G S [HDMI]
Use the separately sold cable with the camera to playback recorded images on your
TV. This function is available during shooting. Connect the camera to an HD TV using
an HDMI cable to view high-quality images on a TV screen.
Type A
HDMI cable
(Connect to the HDMI connector
on the TV.)
HDMI connector (type D)
Connect the TV and camera and switch the input source of the TV.
• When an HDMI cable is connected, images are displayed on both the television and the
camera monitor. Information is displayed on the television screen only.
• For details on changing the input source of the TV, refer to the TV’s instruction manual.
• Depending on the TV’s settings, the displayed images and information may become
cropped.
• If the camera is connected via an HDMI cable, you will be able to choose the digital video
signal type. Choose a format that matches the input format selected with the TV.
C4K C4K via HDMI output.
4K Priority is given to 4K HDMI output.
1080p Priority is given to 1080p HDMI output.
720p Priority is given to 720p HDMI output.
480p/576p 480p/576p HDMI output.
• Do not connect the camera to other HDMI output devices. Doing so may damage the
camera.
• HDMI output is disabled while the camera is connected to a computer via USB.
• When [Record Mode] is selected for [Output Mode] (P. 146), movies will be output at the
resolution selected during recording. The images cannot be displayed on the connected
TV if the TV does not support the record mode.
• 1080p output will be used in place of [4K] or [C4K] while the camera is being used to take
photographs.
Using the TV remote control
The camera can be operated by a TV remote control when connected to a TV that
supports HDMI control. g [HDMI] (P. 168)
The camera monitor turns off.
• You can operate the camera by following the operation guide displayed on the TV.
• During single-frame playback, you can display or hide the information display by
pressing the “Red” button, and display or hide the index display by pressing the
“Green” button.
• Some televisions may not support all features.

Olympus E-M5 Mark III Specifications

General

Flip-out screen	-
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	Yes
Display resolution (numeric)	1037000 pixels
Magnification	1.37 x
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio system	stereo
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Flash modes	Auto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	256000
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLS‑50
Battery life (CIPA standard)	310 shots
Product color	Black
Image editing	Crop, Resizing, Trimming
Photo effects	Black&White, Sepia
White balance	Flash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modes	Auto, Manual, Program, Scene
Self-timer delay	2, 12 s
Digital zoom	- x
Focal length range	14 - 150 mm
Maximum aperture number	4
Minimum aperture number	5.6
Bluetooth version	4.2
Megapixel	20.4 MP
Camera type	MILC
Sensor type	Live MOS
Total megapixels	21.8 MP
Image sensor size	4/3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888

Weight and Dimensions

Depth	49.7 mm
Width	125.3 mm
Height	85.2 mm
Weight	366 g
Weight (including battery)	414 g
