214
EN
Cautions
7
Optional Accessories
Grip (ECG-5)
The grip helps you keep the camera steady when using large lenses.
Make sure to turn the camera off when attaching and removing the grip.
Part names
Shutter button
Front dial
Removal knob
Connector cap
Attaching the Grip
Before attaching the grip, remove the
connector cover (a) from the bottom of the
camera and the connector cap (b) from
the ECG-5. Once attached, make sure the
ECG-5 removal knob is tightly secured. Be
sure to replace the connector cover on the
camera when the ECG-5 is not in use.
a
a
b
Store the connector cover (a) in the ECG-5
Main Speci cations (ECG-5)
Dimensions Approx. 128.4 mm (W) × 76 mm (H) × 60.2 mm (D)
(5.1" × 3.0" × 2.4")
Weight Approx. 121 g (4.3 oz.) (excluding battery and terminal cap)
Splash resistance
(when attached to camera)
Type Equivalent to IEC Standard publication 60529 IPX1
Do not use your nail to turn the removal knob. Doing so could result in injury.
Only use the camera within the guaranteed operating temperature range.
Do not use or store the product in dusty or humid areas.
Do not touch the electrical contacts.
Use a dry, soft cloth to clean the terminals. Do not clean the product with a damp cloth,
thinner, benzine, or any other organic solvents.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M5 Mark III and is the answer not in the manual?

Olympus E-M5 Mark III Specifications

General IconGeneral
Flip-out screen-
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD displayYes
Display resolution (numeric)1037000 pixels
Magnification1.37 x
Viewfinder typeElectronic
Viewfinder resolution2360000 pixels
PictBridgeNo
USB version2.0
HDMI connector typeMicro
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio systemstereo
Memory slots1
Compatible memory cardsSD, SDHC, SDXC
Flash modesAuto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)- m
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity100, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)256000
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLS‑50
Battery life (CIPA standard)310 shots
Product colorBlack
Image editingCrop, Resizing, Trimming
Photo effectsBlack&White, Sepia
White balanceFlash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modesAuto, Manual, Program, Scene
Self-timer delay2, 12 s
Digital zoom- x
Focal length range14 - 150 mm
Maximum aperture number4
Minimum aperture number5.6
Bluetooth version4.2
Megapixel20.4 MP
Camera typeMILC
Sensor typeLive MOS
Total megapixels21.8 MP
Image sensor size4/3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationBody
Still image resolution(s)5184 x 3888
Weight and Dimensions IconWeight and Dimensions
Depth49.7 mm
Width125.3 mm
Height85.2 mm
Weight366 g
Weight (including battery)414 g
