Page #224 background imageLoading...
Page #224 background image
224
EN
Information
8
Shooting tips and information
The camera does not turn on even when a battery is loaded
The battery is not fully charged
Charge the battery with the charger.
The battery is temporarily unable to function because of the cold
Battery performance drops at low temperatures. Remove the battery and warm it by
putting it in your pocket for a while.
No picture is taken when the shutter button is pressed
The camera has turned off automatically
If power saving is enabled, the camera will enter sleep mode if no operations are
performed for a set period. Press the shutter button halfway to exit the sleep mode.
The camera automatically enters sleep mode to reduce the drain on the battery if no
operations are performed for a set period of time. g [Sleep] (P. 174)
If no operations are performed for a set time after the camera has entered sleep mode,
the camera will turn off automatically. g [Auto Power Off] (P. 174)
The ash is charging
On the monitor, the # mark blinks when charging is in progress. Wait for the blinking to
stop, then press the shutter button.
Unable to focus
The camera cannot focus on subjects that are too close to the camera or that are not
suited to autofocus (the AF con rmation mark will blink in the monitor). Increase the
distance to the subject or focus on a high contrast object at the same distance from the
camera as your main subject, compose the shot, and shoot.
Subjects that are dif cult to focus on
It may be dif cult to focus with auto focus in the following situations.
AF con rmation
mark is blinking.
These subjects
are not focused.
Subject with low
contrast
Excessively bright
light in center of frame
AF con rmation
mark lights up but
the subject is not
focused.
Subjects at different
distances
Fast-moving subject Subject not inside
AF area

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M5 Mark III and is the answer not in the manual?

Olympus E-M5 Mark III Specifications

General IconGeneral
Flip-out screen-
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD displayYes
Display resolution (numeric)1037000 pixels
Magnification1.37 x
Viewfinder typeElectronic
Viewfinder resolution2360000 pixels
PictBridgeNo
USB version2.0
HDMI connector typeMicro
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Audio systemstereo
Memory slots1
Compatible memory cardsSD, SDHC, SDXC
Flash modesAuto, Fill-in, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (wide)- m
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity100, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)256000
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 5EV (1/2EV; 1/3EV step)
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLS‑50
Battery life (CIPA standard)310 shots
Product colorBlack
Image editingCrop, Resizing, Trimming
Photo effectsBlack&White, Sepia
White balanceFlash, Fluorescent, Shade, Sunny, Tungsten, Underwater
Shooting modesAuto, Manual, Program, Scene
Self-timer delay2, 12 s
Digital zoom- x
Focal length range14 - 150 mm
Maximum aperture number4
Minimum aperture number5.6
Bluetooth version4.2
Megapixel20.4 MP
Camera typeMILC
Sensor typeLive MOS
Total megapixels21.8 MP
Image sensor size4/3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationBody
Still image resolution(s)5184 x 3888
Weight and Dimensions IconWeight and Dimensions
Depth49.7 mm
Width125.3 mm
Height85.2 mm
Weight366 g
Weight (including battery)414 g
