Parameters Timer/Counter instruction (command): Specify in four letters the instruction
used to create the timer/counter (see below).
Timer/Counter number (command): Specify the timer/counter number used
to define the timer/counter.
Timer/Counter instruction
Instruction Timer/Counter
b
OP1 OP2 OP3 OP4
number
T M H W HIGH-SPEED TIMER
WAIT (TMHW<015>)
000 to 0511
(CVM1-CPU01-EV2
C)
T I M W TIMER WAIT
(TIMW<013>)
(C C U0
and CV500)
0000 to 1023 (other
C N T W COUNTER WAIT
(CNTW<014>)
0000
to
1023
(other
CPUs)
T I M H HIGH-SPEED TIMER
(TIMH(015))
T T I M ACCUMULATIVE
TIMER (TTIM(120))
C N T R REVERSIBLE
COUNTER (CNTR(012))
T I M space TIMER (TIM)
C N T space COUNTER (CNT)
SV (response): The SV of the specified instruction in BCD.
Note A total of four letters are required to specify the instruction. Be sure to include a
space where necessary.
5-17 SV READ 2
Finds the specified timer or counter instruction in the program (main program
area) starting from the specified address and reads the constant SV in 4-digit
BCD or reads the address of the word containing the SV. This command can be
used to specify address in programs only up to 10K words in size.
Note 1. Only the first instruction in the program after the specified address that
meets the specifications will be found.
2. Only the main program will be searched for CVM1 PCs.
3. If the PC is programmed using SFC, only action 0 will be searched. The en-
tire main program will be searched if SFC programming is not used.
Command Format
@ R$
x 10
0
x 10
1
x 10
2
x 10
3
10
0
x 10
1
x 10
2
x 10
3
x 10
0
x 10
1
OP2OP1 OP4OP3
FCSUnit no. TerminatorHeader code Address Timer/Counter instruction Timer/Counter number
*s
Response Format
@ R$
x 10
0
x 10
1
OP2 OP4OP3 x 10
2
x 10
3
x 10
0
x 10
1
x 16
0
x 16
1
OP1
Unit no. FCS TerminatorHeader
code
Response
code
Operand SV
*s
SV READ 2 Section 5-17
