Omron E5DC User Manual

6 Parameters
6 - 14
E5@C Digital Temperature Controllers User’s Manual (H174)
This parameter is set to one of the input values “X” in 4-10-1 Alarm Types.
al-1
Alarm Value 1
Alarm 1 to alarm 4 must be assigned.
The Alarm 1 to 4 Type parameters must not be set
to 0, 1, 4, 5, or 12.
al-2
Alarm Value 2
al-3
Alarm Value 3
al-4
Alarm Value 4
• These parameters set the alarm values for alarms 1 to 4.
• During temperature input, the decimal point position depends on the currently selected
sensor, and during analog input it depends on the Decimal Point parameter setting.
Alarms Other Than an MV Alarm
MV Alarms
 Related Parameters
Input Type (Initial Setting Level): Page 6-43
Scaling Upper Limit, Scaling Lower Limit (Initial Setting Level), and Decimal Point (Initial
Setting Level): Page 6-44
Alarm 1 to 4 Type (Initial Setting Level): Page 6-48
Alarm 1 to 4 Hysteresis (Initial Setting Level): Page 6-52
Standby Sequence Reset (Advanced Function Setting Level): Page 6-64
Auxiliary Output 1 to 4 Open in Alarm (Advanced Function Setting Level): Page 6-65
Alarm 1 to 4 Latch (Advanced Function Setting Level): Page 6-71
Function
Setting range Unit Default
−1999 to 9999 EU 0
Setting range Unit Default
−199.9 to 999.9 % 0.0
See
See
