6 - 47
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-7 Initial Setting Level
6
This parameter sets the type of control when using the simple program function.
ptrn
Program Pattern
• If the program pattern is set to off, the simple program will not operate.
• If the program pattern is set to stop, the RUN/STOP status will change to STOP after the
soak time has expired. If the program pattern is set to cont, control will continue in RUN
status after the soak time has expired.
 Related Parameters
Program Start (Operation Level): Page 6-12
Soak Time Remain (Operation Level): Page 6-13
RUN/STOP (Operation Level) : Page 6-13
Soak Time (Adjustment Level): Page 6-31
Wait Band (Adjustment Level): Page 6-32
Soak Time Unit (Advanced Function Setting Level): Page 6-84
cp
c-cp
Control Period (Heating)
Control Period (Cooling)
The cooling control output and heating control
output must be assigned to relay or voltage
outputs (for driving SSR).
The control must be set to 2-PID control.
For the Control Period (Cooling) parameter, the
control must be set to heating/cooling control.
• These parameters set the output periods. Set the control periods taking the control
characteristics and the electrical life of the relay into consideration.
• For standard control, use the Control Period (Heating) parameter. The Control Period
(Cooling) parameter cannot be used.
• When the heating control output is a current output, the Control Period (Heating)
parameter cannot be used.
• For heating/cooling control, the control period can be set independently for heating and
cooling. The Control Period (Heating) parameter is used for the heating control output,
and the Control Period (Cooling) parameter is used for the cooling control output.
 Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-45
000
Function
Setting
Setting range Default
off Simple program function turned OFF off
stop Go to STOP mode at end of program.
cont Continue in RUN mode at end of program.
See
See
Function
Setting
Parameter name Setting range Unit Default
Control Period
(Heating)
0.1, 0.2, 0.5, 1 to 99 Seconds 20 for relay output
2 for voltage output (for driving
SSR)
Control Period
(Cooling)
0.1, 0.2, 0.5, 1 to 99 Seconds 20 for relay output
2 for voltage output (for driving
SSR)
See
See
