32
Refer to 4-2 Setting Mode.
Hold Measured Value When the HOLD input is turned ON, measurement stops and the input mea-
sured just before the HOLD input turned ON is held. While the HOLD input is
ON, the K3NR holds display output, comparative output, and BCD output.
When the comparative output from the Output Board is connected to the
HOLD input terminal, the value measured immediately after the occurrence
of an error can be obtained.
Performance Characteristics
Accuracy of measurement
±0.02% rdg ± 1 digit (ambient temperature: 23°C ± 5°C)
Measurement range Sensor with transistor output: 0.5 mHz to 50 kHz
Sensor with relay output: 0.5 mHz to 30 Hz
ON/OFF pulse width
Sensor with transistor output: 9 µs min.
Sensor with relay output: 15 ms min.
Response time Output configuration
Relay output Transistor
output
BCD and
transistor output
Linear and
transistor output
Communication
and transistor
output
Comparative output 200 ms max.
BCD output --- --- Refer to page 115. --- ---
Linear output --- --- --- 220 ms max. ---
REFERENCE
Rotational Difference: f4
Section 3-4
