Appendix ASpecifications
96
Input/Output Ratings
Relay Contact Output
(Incorporating a G6B Relay)
Item Resistive load (cosφ = 1) Inductive load (cosφ = 0.4, L/R = 7 ms)
Rated load 5 A at 250 VAC; 5 A at 30 VDC 1.5 A at 250 VAC, 1.5 A at 30 VDC
Rated carry current 5 A max. (at COM terminal)
Max. contact voltage 380 VAC, 125 VDC
Max. contact current 5 A max. (at COM terminal)
Max. switching capacity 1,250 VA, 150 W 375 VA, 80 W
Min. permissible load
(P level, reference value)
10 mA at 5 VDC
Mechanical life 50,000,000 times min. (at a switching frequency of 18,000 times/hr)
Electrical life
(at an ambient temperature of
23°C)
100,000 times min. (at a rated load switching frequency of 1,800 times/hr)
Transistor Output
Rated load voltage 12 to 24 VDC
+10%
/
–15%
Max. load current 50 mA
Leakage current 100 µA max.
BCD Output
I/O signal name Item Rating
Inputs
REQUEST, HOLD, MAX, MIN,
Input signal No-voltage contact input
RESET
Input current with no-voltage input 10 mA
Signal level ON voltage: 1.5 V max.
OFF voltage: 3 V min.
Outputs
DATA, POLARITY, OVERFLOW,
Rated load voltage 12 to 24 VDC
+10%
/
-15%
DATA VALID, RUN
Max. load current 10 mA
Leakage current 100 µA max.
Note Logic method: negative logic
Linear Output
Item 4 to 20 mA 1 to 5 V 1 mV/10 digits (see note)
Resolution 4,096
Output error ±0.5% FS ±1.5% FS
Permissible load resistance 600 Ω max. 500 Ω min. 1 KΩ min.
Note For the 1 mV/10-digit output, the output voltage changes for every 40 to 50 increment in the display value.
Communications
Item RS-232C, RS-422 RS-485
Transmission method 4-wire, half-duplex 2-wire, half-duplex
Synchronization method Start-stop synchronization
Baud rate 1,200/2,400/4,800/9,600/19,200/38,400 bps
Transmission code ASCII (7-bit)
Communications Write to K3NX Comparative set value, scaling value, remote/local programming, forced zero
control, reset control of maximum/minimum values, and other setting mode
items excluding communications conditions.
Read from
K3NX
Process value, comparative set value, maximum value, minimum value, model
data, error code, and others
Note For details, refer to Communication Operation Manual.
