Omron NS5-SQ00 V2 Series User Manual

Section 5
Connecting to Host via Ethernet or
Controller Link
This section describes the methods for connecting the PT to the host using the PT’s Ethernet
interface and the Controller Link Interface Unit.
5-1 Connecting to Host Via Ethernet....................................................................................... 5-2
5-1-1 Host Types and Settings ........................................................................................... 5-3
5-2 Connecting to the Host Using Controller Link................................................................ 5-15
5-2-1 What Is a Controller Link Network? ...................................................................... 5-15
5-2-2 Data Links .............................................................................................................. 5-16

Omron NS5-SQ00 V2 Series Specifications

General

Display Size	5.7 inches
Resolution	320 x 240 pixels
Touchscreen Type	Analog Resistive
Backlight	LED
Brightness	300 cd/m²
Backlight Life	50, 000 hours
Power Supply	24 VDC
Operating Temperature	0 to 50 °C
Storage Temperature	-20 to 60 °C
Humidity	10 to 90% RH (non-condensing)
Display Type	TFT color LCD
Communication Ports	RS-232C, RS-422/485
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude, 57 to 150 Hz, 9.8 m/s²
Shock Resistance	147 m/s² (15 G)
Protection Rating	IP65
Weight	0.8 kg
