A - 5
Appendices
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
A-2 Dimensions
A
A-2-4 Option Board
A-2-4 Option Board
NX1W-CIF01
NX1W-CIF11/-CIF12
NX1W-ADB21/ -DAB21V/ -MAB221
35.9
13.5
35.9
0.7
0.7
Unit: [mm]
8.8 0.6
3.5
35.9
13.5
35.9
0.7
0.7
3.5
Unit: [mm]
5.6 0.6
36.4
36.4
0.45
0.45
NX1W-ADB21 NX1W-DAB21V NX1W-MAB221
28.2
Unit: [mm]
5.4
0.6
