3 Configuration Units
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
3-3 Serial Communications Option Board
3
3-3-2 Purpose
A Serial Communications Option Board is used to connect the CPU unit to general-purpose compo-
nents with a serial interface in order to perform data I/O processing. The general-purpose components
with a serial interface includes a bar code reader, Temperature Controller and PT.
An RS-232C and RS422A/485 ports are supported, and up to two ports can be added to the CPU Unit.
The supported communication protocols are the host link, Modbus-RTU master, and no-protocol.
Refer to the NX-series NX1P2 CPU Unit Built-in I/O and Option Board User’s Manual (Cat. No. W579)
for details on how to use the Option Boards.
Item Specification
Model NX1W-CIF01 NX1W-CIF11 NX1W-CIF12
Communications port
One RS-232C port One RS-422A/485 port One RS-422A/485 port (iso-
lated)
Communications
method
Half-duplex
Synchronization method Start-stop synchronization
Baud rate 1.2/2.4/4.8/9.6/19.2/38.4/57.6/115.2 kbps
Transmission distance 15 m50 m500 m
Supported protocol Host link, Modbus-RTU master, and no-protocol
Connection type
Screwless clamping terminal
block (9 terminals)
Screwless clamping terminal block (5 terminals)
Applicable wire size AWG28 to 20 AWG24 to 20
Dimensions (mm)
*1
*1. Projecting parts such as a terminal block is not included. When the Option Board is mounted to the CPU Unit, it protrudes
through the CPU Unit surface. The details are explained in 5-3-13 Assembled Appearance and Dimensions on page 5-35.
35.9 × 35.9 × 13.5 (W×H×D)
Weight 16 g13 g14 g
Power consumption
Included in the CPU Unit power consumption.
The Option Board power consumption is included in the definition of the CPU Unit power con-
sumption.
Isolation method
No isolation
Isolation
*2
*2. The terminals are isolated from the internal circuits of the CPU Unit.
3-3-2 Purpose
