9-24
9-5 Interface Monitor Settings
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
9
Details on Servo Parameter Objects
9-5 Interface Monitor Settings
Set the function and logic for general-purpose input 1 (IN1).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 2 (IN2).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 3 (IN3).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 4 (IN4).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 5 (IN5).
Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
Sequence I/O Signals on page 7-1.
Set the function and logic for general-purpose input 6 (IN6).
 Refer to the Details of Control Inputs in Control Input Details on page 3-17, as well as 7-1
3400 hex
Input Signal Selection 1
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0094 9494
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3401 hex
Input Signal Selection 2
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0081 8181
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3402 hex
Input Signal Selection 3
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0082 8282
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3403 hex
Input Signal Selection 4
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0022 2222
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3404 hex
Input Signal Selection 5
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
002B 2B2B
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
3405 hex
Input Signal Selection 6
Setting
range
0 to 00FF FFFF hex Unit −
Default
setting
0021 2121
hex
Data
attribute
C
Size 4 bytes (INT32) Access RW PDO map Not possible.
All
