Omron OMNUC G5 Series User Manual

2-50
2-4 External and Mounting Dimensions
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
2
Models and External Dimensions
External Regeneration Resistor Dimensions
External Regeneration Resistor
R88A-RR08050S/-RR080100S
R88A-RR22047S/-RR22047S1
R88A-RR50020S
20
t1.2 104
122
130
43.5
28
4.2
6
Thermal switch output
500
ϕ3 (0.75 mm
2
)
ϕ1.5 (0.3 mm
2
)
20
t1.2 200
220
230
62 48
4.2
6
Thermal switch output
500
ϕ3 (0.75 mm
2
)
ϕ1.5 (0.3 mm
2
)
360
386
402
4325 10
78
76
40
5.2
