About this Manual:
This manual describes the installation and operation of the C200H-AD003 Analog Input Unit, the
C200H-DA003/DA004 Analog Output Unit, and the C200H-MAD01 Analog I/O Unit and includes the sec-
tions described below.
The C200H-AD003 Analog Input Unit converts analog sensor output to digital format and transmits it to
C200H, C200HS and C200HX/HG/HE PCs.
The C200H-DA003 and C200H-DA004 Analog Output Units convert C200H, C200HS, and C200HX/HG/
HE digital data to analog format for output.
The C200H-MAD01 Analog I/O Unit provides both input and output functions.
Please read this manual carefully and be sure you understand the information provided before attempting
to install and operate the C200H-AD003, C200H-DA003, C200H-DA004, or C200H-MAD01.
Section 1 describes the features and system configuration of the C200H-AD003 Analog Input Unit, the
C200H-DA003 and C200H-DA004 Analog Output Units, and the C200H-MAD01 Analog I/O Unit, and
explains the operations that they have in common.
Section 2 provides the information required to install and operate a C200H-AD003 Analog Input Unit.
Section 3 provides the information required to install and operate a C200H-DA003 or C200H-DA004
Analog Output Unit.
Section 4 provides the information required to install and operate a C200H-MAD01 Analog I/O Unit.
The Appendices provide dimensions, model change differences, sample programs, and data memory
coding sheets.
WARNING Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
!
